![Ea2 DE903 [12/13] Low battery indication](/views2/1962608/page12/bgc.png)
ENGLISH 9 ENGLISH 10
8.3 Daily Snooze Alarm Function:
• Press “MODE/SET” button (B6) to select to view :
Time Weekday Alarm Time (“AL” Shown on the LCD)
• When viewing the Alarm Time, hold “MODE/SET” button (B6) for 3 seconds to enter
Alarm Time setting. Press “-” (B4) or “+” (B7) button to adjust the alarm time. Press
“MODE/SET” button (B6) to conrm the setting.
• Press “AL ON/OFF” button (B1) to switch alarm on or off. If it is on, “
” shown on
the LCD.
• When Alarming, press “SNOOZE / LIGHT” button (B2) to activate the snooze alarm,
(“ ” ash on the LCD). The alarm will snooze for 5 minutes, then it alarms again.
This snooze function can be enabled for maximum 7 times.
• Except “Snooze” button, press any button to stop the snooze alarm.
8.4 Dual Time Setting Function
• Press “MODE/SET” button (B6) to select to view :
Time
Weekday Alarm Time Dual Time (“DT” shown on the LCD)
• When viewing the Dual Time, hold “MODE/SET” button (B6) for 3 seconds to enter
Dual Time setting. “Hour” & “Min” digits ash. Press “-” (B4) or “+” (B7) button to adjust
the “hour”, press “MODE/SET” button (B6) to conrm and quit the setting.
9. Low battery indication:
The low battery icon “ ” will appear at particular channel indicating that thermo
sensor unit of the channel is in low battery status. The batteries should be replaced.
10. Backlight
Press “SNOOZE/LIGHT” button (B2), back light states for 5 seconds.
Indoor Data:
Temperature range: 0 to 50°C [32 to 122°F]
Temperature Units Measured: °C or °F [switchable]
Humidity Range: 20% to 99%
Weather Forecast:
5 icons [sunny, slightly cloudy, cloudy,
rainy & snow]
Outdoor Data:
Transmission distance: (open area) 30m @ 433MHz
Temperature range: -40 to 50°C [-40 to 122°F]
Mount: wall / table
Main Unit Dimensions: w80 x h158 x d19 mm
Thermo Sensor Dimensions: w65 x h84 x d18 mm
Battery Requirements:
Base Station [indoor]: 3 x AAA batteries
Sensors [outdoor]: 2 x AAA batteries
11. Precautions
• Use a pin to press the reset button (B9) if the Unit does not work properly.
• All Setting Modes will automatically exit in 15 seconds without any adjustment.
• The clock loses its time information when the battery is removed.
• Avoid placing the clock near interference sources/metal frames such as computer or
TV sets.
• Do not expose it to direct sunlight, heavy heat, cold, high humidity or wet areas
• The outdoor sensor must not be set up and installed under water. Set it up in away
direct sunlight and Rain
• Never clean the device using abrasive or corrosive materials or products. Abrasive
cleaning agents may scratch plastic parts and corrode electronic circuits
• If there is any inconsistency of weather forecast between Local Weather Station and
this unit, the Local Weather Station's forecast should prevail. The manufacturer will not
take responsible for incorrect forecasting from this unit
12. Specications
