13
INSTRUCTION MANUAL
2.3. PUTTING ON THE PULSE-CHEST BELT >>> P08
step 1 First connect the one side of the pulse transmitter with the
elastic strap, as shown. Press the ends of the pulse-chest belt
into the plastic holder of the elastic strap
step 2 Place the pulse transmitter just below your chest and guide
the elastic strap over your back to the other end of the pulse
transmitter
step 3 Connect the second end of the plastic strap to the pulse
transmitter
step 4 Use the size adjustment of the elastic strap to adjust the chest
belt to your chest size
Please note:
- Do not adjust the chest belt too loose; if it is too loose it can slip if
there are jolts (e.g. when walking)
- When putting on the chest belt moisten the electrodes so that trouble-
free function is also ensured when starting exercise, before contact is
established through sweat.
- Range of the pulse-chest belt transmitter = 0.90 m
2.4. MOUNTING THE COMPUTER ON THE WRIST BAND
>>> P09
step 1 Insert the computer into the opened wrist band
step 2 Insert the lock into the wrist band holder from below
step 3 Turn the lock with a coin to tighten it
ATTENTION: Never use a screwdriver to operate the lock. This could
damage the lock (if the lock should be damaged then you can get the
lock as original replacement part)
3. INITIAL OPERATION
3.1. INITIAL OPERATION, AC-BUTTON >>> P09-2
After inserting the batteries we recommend that you first reset the de-
vice to factory settings to ensure that no residual data from the quality
control process remains in the computer. This puts the computer into
an assured start mode.
- Press the AC button for approximately 2 seconds with a sharp object,
such as a pencil
3.2. LANGUAGE SELECTION
3sec. ç Setting mode LANGUAGE SELECT
step 2 ‚ Confirm LANGUAGE SELECT with M
step 3 ∂ ƒ Press the up or down button until the desired langu-
age appears
step 4 ‚ Confirm your language selection with M
3.3. MANUAL PAIRING - INITIAL OPERATION WIRELESS SYSTEM
For initial operation of the digital wireless system manual pairing must
ALWAYS be executed. Manual pairing ensures that the computer learns
the coding of the transmitter you are using.
step 1 Insert the computer into the twist-click holder
step 2 Ensure that there are no ANT+Sport digital transmitters other
than the transmitter you are using within a 5-meter area
around the computer
Your computer will randomly select one of 128,000 codes. This ensures
that signals of other transmitters are not received or processed (e.g.
when riding in a group). If dashes are shown in the display, in spite
of pairing, you must repeat the manual pairing process. In doing so
