INSTRUCTION MANUAL

1.1. GENERAL

1.2. IMPORTANT INSTRUCTIONS FOR THE DIGITAL WIRELESS SYSTEM

Your VDO series Z1 works entirely without cable; it works with double

digital wireless transmission based on well-established ANT+Sport®

wireless protocol. The ANT+Sport® wireless protocol has already

been successfully implemented by manufacturers such as Garmin,

Specialized, and Suunto. Speed signals, cadence signals (optional) to

the respective receiver (computer) as digital and coded signals. Signal

coding ensures that only the data of your own speed, and cadence

(optional) transmitters are processed (this is advantageous when riding

in a group).

The ANT+Sport digital technology is signiﬁcantly more reliable than the

technology of older analog systems. The ANT+Sport technology uses

standard industrial wireless components, and it can best be compared

to the technology used in modern WLAN networks. The connection

between transmitter and receiver is more stable, and subject to

signiﬁcantly less frequent malfunction, and it is virtually completely

safeguarded from data loss.

The speed transmitter has a memory component that buffers data eve-

ry 65 sec. Thus no data is lost if there is a malfunction lasting for this

duration.After the malfunction this data will be resent to the computer.

Subsequently the following data will be updated:

Daily distance

Ride time

Average speed

Navigator

Total distance

Total ride time

After a malfunction the data can change suddenly = updating the

computer. Initial operation of a completely digital system requires

somewhat more care than does initial operation of conventional analog

systems. The ﬁrst time batteries are inserted, or after a battery change,

the transmitter automatically generates a new code. The computer has

to learn this code. To do this you must execute a DIG CONNECT SET.

Strictly follow the instructions in chapter 3.3.1. to do this.

ATTENTION: Your VDO computer is not suitable for use on motorcycles.

1.3. CONTROL SYSTEM - OPERATION

The control system of your computer is based on dual assignment of

the 4 main buttons. In this regard the devices distinguishes between

operation mode and setting mode.
