INSTRUCTION MANUAL

1.5. EXTENSION OPTIONS & ACCESSORIES

Extension option: You have the possibility of extending your computer

with the cadence extension set

In this case the following cadence functions are available to you:

Actual cadence

Average cadence

Maximum cadence

In addition you can also get the following original VDO

replacement parts from your dealer

Designation article number

Universal handlebar holder - wireless art. no. 5503

Magnet S/M for speed impulses art. no. 4410

Magnet L/XL for speed impulse art. no. 4412

Cadence magnet art. no. 4411

Speed transmitter art. no. 6602

Cadence kit art. no. 6603

Wrist band art. no. 6607

Wrist band lock art. no. 6608

Universal mount kit art. no. 6601

When purchasing look for the VDO Cyclecomputing original equipment

logo. Only products bearing this logo are authorized by VDO Cyclecom-

puting for use with your computer.

2. INSTALLATION

2.1. BATTERY INSTALLATION

2.1.1. BATTERY INSTALLATION - COMPUTER AND SPEED/CADENCE

TRANSMITTER >>> P02

step 1 Insert the battery into the computer/transmitter housing with

the + pole up.

step 2 Ensure that the battery is not tilted.

step 3 Ensure that the rubber seal lies smoothly on the lid of the

battery compartment.

step 4 Insert the battery compartment lid into the opening and use

a coin to ﬁrmly turn the battery door to right until the stop

(approximately 1/3 turn)

TIP for changing batteries: VDO recommends changing the batteries

yearly to avoid undesired data loss. Thus strictly ensure that you note

the entered wheel sizes as well as the previous ridden kilometers for

bike 1 & bike 2, as well as the total altitude difference for bike 1, bike

2, and the altitude difference walked. Reprogram this information after

inserting the new batteries.

ORIGINAL

EQUIPMENT
