13
EN CS DA DE ES FR NL PL RU SV
LCD/Sound Menu
Backlight:
By default, the display will remain lit
for about 10 seconds when a button
on the recorder is pressed.
1 Select [
Lighting Time
], [
Dim
Light Time
] or [
Brightness
].
2 Select the options.
When [Lighting Time] is selected:
[ 5seconds ] [ 10seconds ] [ 30seconds ]
[ 1minute ]:
Set the backlight duration.
When [Dim Light Time] is
selected:
[ 30seconds ] [ 1minute ] [ 2minutes ]
[ 5minutes ]
[ Always On ]:
Set the time after which the
backlight dims.
c
Adjust the start/stop actuation
level:
While the recorder is in recording
mode, press the 9 or 0 button
to adjust the actuation level.
• The VCVA level can be set to any of
15 different values.
• The higher the value is, the more
sensitive the recorder can react to
sounds. At the highest value, even
the faintest sound will activate
recording.
• The VCVA actuation level can be
adjusted according to the ambient
(background) noise.
C Start level (moves to the right/
left according to the set level)
• The start/stop actuation level also
varies depending on the selected
microphone sensitivity mode.
• To ensure successful recordings,
prior testing and adjustment of
the start/stop actuation level is
recommended.
Device Menu
Card Select:
By default, the recording media is set
to [ SD Card ] by the manufacturer.
• The recording media ([
] or [ ])
will appear on the display.
Cue/Rev:
The playback sound of Cue and
Review operation and Cue and
Review speed can be set.
1 Select [
Sound
] or [
Speed
].
[ Sound ]:
Set the playback sound of Cue
and Review to On or Off.
[ Speed ]:
Set the Cue and Review speed.
2 Select the options.
When [Sound] is selected:
[ On ]:
Activate the playback sound of
Cue and Review.
[ Off ]:
Disables this function.
When [Speed] is selected:
You can adjust the Cue and
Review speed level from
[ Speed 1 ] to [ Speed 5 ].
• Cue and Review speed level
becomes faster as the numerical
value becomes larger.
Power Save:
By default, the recorder will enter
into Power Save mode if not used for
more than 10 minutes.
[ 5minutes ] [ 10minutes ] [ 30minutes ]
[ 1hour ]:
Set the length of time before the
recorder will enter into Power Save
mode.
[ Off ]: Disables this function.
• If any button is pressed, time count
will restart.
Time & Date:
Setting the time and date beforehand
enables easier file management.
For details, see “ Setting time and
date [Time & Date] ”.
USB Class:
You can set the USB class of this
recorder with a USB connection to
[ Composite ] or [ Storage Class ].
[ Composite ]:
In the 3 classes of Storage, USB
audio and human interface device,
USB connection is possible. While
connected via USB in [ Composite ],
the recorder can be used as the USB
speaker and the USB microphone in
addition to storage class.
[ Storage Class ]:
USB connection is possible in only
storage class.
Reset Settings:
To reset the menu settings to their
default values use [ Reset Settings ]
under [ Device Menu ], or use the
ODMS and DSS Player software.
Format:
Cards that have been used in non-
Olympus devices, or cards that are
not recognized by the recorder, must
be formatted before they can be used
with the recorder.
• Formatting the card will erase all
the stored data, including locked
files.
For details, see “ Formatting the card
[Format] ”.
When [Brightness] is selected:
[ 01 ] [ 02 ] [ 03 ]:
Sets the brightness of the
backlight when lit.
LED:
You can set it so the record indicator
light does not turn on.
[ On ]:
LED light will be set.
[ Off
]:
LED light will be canceled.
Beep:
When the Beep is set to [ On ], the
recorder will beep in case of error.
[ On ]:
Beep is enabled.
[ Off ]:
Beep is disabled.
Language (Lang):
You can set the language for the
recorder’s user interface.
[ Čeština ] [ Dansk ] [ Deutsch ] [ English ]
[ Español ] [ Français ] [ Nederlands ]
[ Polski ] [ Русский ] [ Svenska ]:
• The languages available may vary
depending on the country/region
where the product is purchased.
