29
BACK PANEL OF THE TV
SIDE PANEL OF THE TV
HDMI1(ARC)
HDMI2
DIGITAL
AUDIO OUT
ANT
COMMON
INTERFACE
AV
1. HDMI: HDMI connectors (HDMI1 connector supports ARC function).
2. ANT: Antenna connector.
3. DIGITAL AUDIO OUT: Digital audio output.
4. AV: Audio-video (mini).
5. CI: General interface.
6. Headphone jack
NOTE: input/output connection options may vary, depending on the specific
product model.
Battery replacement
Replace the batteries in time. To make the remote control work, install the
batteries according to the instructions.
ATTENTION! If the batteries are installed incorrectly, an explosion may occur.
Replace the batteries with batteries of the same or similar type only.
START OF OPERATION
Installing batteries in the remote control
1.Open the cover on the back of the remote control.
2. Install two AAA batteries. Make sure that the «+» and «-» at the ends of the
batteries match the pointers inside the compartment.
3. Close the cover.
Battery Usage Notes:
Using the wrong type of batteries can cause leaks and/or explosion.
Note:
If the power is accidentally turned off, the TV will automatically return to standby
mode after the power supply is restored. To ensure the normal use of the TV,
frequent power off and on is prohibited, therefore, in case of accidental power off,
it is recommended to disconnect the power cord from the outlet.
TURNING THE TV ON AND OFF
• Turning on the TV
Plug the TV into an outlet. If the TV has a power switch, turn it first of all. In
standby mode, press the power button on the remote to turn on the TV.
• Turning off the TV
Press the power button on the remote to turn on standby mode.
Do not leave the TV in standby mode for a long time. We recommend to disconnect
the power cord.
Starting setup
When you start the TV for the first time, the setup start MENU appears on the
screen, the items of this MENU can also be found in the main MENU, so you can
change the values after you have set them.
ADVICE: Make sure the antenna is connected.
• Setting the desired language
Press the buttons ▲/▼ to select the language of the MENU and messages.
• Country selection.
Press the buttons ▲/▼ to select the country of residence, then click ►,
• Choose your time zone.
Press the buttons ▲/▼ to select time zone, then click the button ►,
• Select the usage mode.
Press the buttons ▲/▼ to select the «Дом» («Home») or «Магазин» («Store»)
mode, then press the button ►,
To save electricity, it is recommended to set the mode «Дом» («Home»). If you
want to set the «Магазин» («Store») mode, a message will appear, asking you
to confirm your choice.
• Select the type of antenna (air, cable).
Press the buttons ▲/▼ to select the type of antenna then press the button ►.
For more information, see «Автонастройка» («Autotune») in the MENU <<Каналы»
(«Channels»).
• Autosearch
Press the button ► to start autosearch.
First comes the setup of DTV (digital TV channels), click [MENU] and ◄ to skip the
DTV setup. This is followed by setting up ATV (analog TV channels), press MENU
and ◄ to skip the ATV setup.
NOTE:
• If the TV did not find the channels, check the antenna connections and the
country you selected, and then try to catch the channels again by auto-search
or manual search.
• If the TV receives only a few channels, it means that the input TV signal is weak
enough. Modification of the antenna is recommended.
Channel Selection
• Use CH ▲/▼ on the remote control.
• Press СН▲ to switch channels forward.
• CH ▼ to switch channels back.
• Using the numeric buttons 0-9.
You can select a channel by pressing the numbers from 0 to 9.
The TV will switch to the corresponding channel, the number you have pressed.
For example, if you need to select channel 5, press 5, if you need to select
channel 20, press 2 and 0 in a row.
So
und Settings
• Press VOL+/- on the remote control to adjust the sound.
• If you want to turn off the sound completely, press
(MUTE).
• To resume the sound, press
(MUTE) or just turn up the sound.
Signal source selection
To select the signal source, press the SOURCE button on the remote control. Press
the buttons ▲/▼ to switch the input source and press ENTER to confirm your
selection.
Navigation in the MENU
1. Press the MENU button to display the main MENU.
2. Press the buttons ◄/► to move to the main MENU. You can choose «Канал»
(Channel), «Изображение» (Picture), «Звук» (Sound), «Таймер» (Timer), «Блоки-
ровка» (Lock), «Опции» (Option).
3. Press ENTER to ENTER the subMENU.
4. Press the buttons ▲/▼ to select the desired parameter.
5. Press the buttons ◄/►to adjust the value.
6. Press the MENU button to return to the previous MENU.
7. Press the EXIT button to EXIT the MENU.
NOTE:
- When an item in the MENU displayed in grey, it means that this item is not
available or cannot be configured.
- Some MENU items may be hidden depending on the modes and the signal
sources used.
- The buttons on the TV perform the same functions as the corresponding buttons
on the remote control. If your remote control is lost or does not work, you can use
the buttons on the TV screen to select a MENU. This instruction shows navigation
with the remote control.
