Telefunken TF-DVBT203 [4/29] Connection

Connection

Antenna input

• Connect an external DVB-T antenna

(cable) connector to the antenna RF IN.

The signal in the block cable antenna

can fail to contain DVB-T/T2 signal due to the

carrier frequency altered by the cable network

operator.

RF output

• Connect the RF output jack to an antenna

cable to bypass the digital signal to other

devices.

HDMI-out

• If your TV has an HDMI video output,

connect it to an HDMI output of this unit using

a special HDMI cable (not included).

Stereo audio output

• Connect the left (white) and right (red)

terminal of the stereo audio output to the

corresponding audio inputs on your TV using

the supplied RCA-type cable.

Composite vudeo (CVBS) output

• Connect the yellow video output to the

composite video input on your TV using the

RCA cable (included) for transmitting the

composite video signal.
