WMF 9000 F 03.8900.5010 [79/88] Appendix technical data

User Manual WMF 9000 FGV

Appendix: Technical data

Technical data for coffee machine

External dimensions Width 450mm

Height 782mm (with 4mm feet, without lock)

Depth 605mm

Ground coffee hopper approx. 2,500g each

Weight empty approx. 65kg

Water supply

On site:

• ½" (TW12) with main shutoff valve

anddirtﬁlter (250µm)

• Min. 0.36MPa (3.6bar)

ﬂow pressure at 6l/min

• maximum inlet temperature 35°C.

Machine:

• Boiler feed ½" (TW12)

• Rinsing line ⅜" (TW8)

Water quality For drinking water with carbonate hardness

from 9°dKH or higher, aWMFwater ﬁlter must

be ﬁtted.

Water drain tube (optional) Hose aminimum of DN 40, minimum

downward slope of 2cm/m

Use at elevation above sea level < 2,000m

We reserve the right to make technical modiﬁcations.

The capacity depends on the size of the ground coffee.

These speciﬁcations (IEC60335–2-75) for the water connection to the coffee

machine apply in EU member states. It may be necessary to also observe

additional country-speciﬁc regulations. Outside the EU countries acceptance of

the standards quoted is to be checked by the legal entity or natural person who

wishes to use the coffee machine.

This takes the normal pressure losses via water supply set and water ﬁlter into

account. As aresult, the ﬂow pressure of 0.2MPa (2bar) at 6l/min required by

the machine for maximum hourly output will be ensured.
