Falmec LAGUNA ISOLA WHITE [2/2] Mount 8 gaskets b between the hood and the extension as shown
![Falmec LAGUNA WHITE 60 [2/2] Mount 8 gaskets b between the hood and the extension as shown](/views2/1976887/page2/bg2.png)
A
B
A (1 : 3.8)
A
A
A
A
C
C
B B
LAGUNA ISOLA
Montaggio staffa sicurezza e guarnizioni
Mounting instruction for safety plate and the gaskets
1- Montare la cappa seguendo le istruzioni del libretto
Mount the hood following the istruction booklet
2- Fissare la staffa di sicurezza (A) seguendo questa istruzione
Mount the safety plate (A) according this instruction
cod. 110020111
3- Inserire n°8 guarnizioni antivibrazioni (B) tra cappa e prolunga come
da particolare C
Mount 8 gaskets (B) between the hood and the extension as shown
on the fig. C
