Aten CV211 [11/48] Installation

- 11 -

Installation

Setting up the CV211 is quick and easy with plug-and-play

functionality in just a few steps. Numbers 1–4 below refer to the

diagram on the next page:

1. Connect the USB Type-A end of the USB Type-A to USB

Mini-B cable (included with this package) to the USB port of

the laptop.

2. Connect the USB Mini-B end of the USB Type-A to USB

Mini-B cable (included with this package) to the Mini USB port

of the CV211.

3. Connect the CV211’s USB Type-A connector to a USB port

on the target computer.

4. Connect the CV211's VGA connector to a VGA port on the

target computer.

5. When a successful connection between the target computer

and the laptop is established, the CV211’s blue LED will flash

on/off at a fast pace.

Note: Make sure the computers and devices that the CV211

connects to are also properly grounded.

To prevent damage to your installation from power

surges or static electricity. It is important that all

connected devices are properly grounded.
