Aten RCM416 [215/302] Firmware upgrade recovery

Chapter 10. Maintenance

197

Firmware Upgrade Recovery

Should the switch’s main firmware upgrade procedure fail, and the switch

becomes unusable, the following firmware upgrade recovery procedure will

resolve the problem:

1. Power off the switch.

2. Press and hold the reset button in (see reset button, page 13).

3. While holding the reset button in, power the switch back on.

This causes the switch to use the original factory installed main firmware

version. Once the switch is operational, you can try upgrading the main

firmware again by logging on to the KVM over IP switch via web browser (see

Main Firmware Upgrade, page 196).
