Control Box Gen. 2 Setup Guide
5
9 IR receiver / LED Passes the functions of a remote control to the Control Box
in learning mode. The distance between the IR remote and
the receiver window should be kept under 10 cm with a
direct line of sight.
The LED blinks green to indicate the unit is receiving
signals from an IR remote control
The LED lights green to indicate entering learning mode,
or IR learning success with the buzzer beeping once.
10 USB port / LED Note: Control Box Gen 2. is compatible with USB drivers
in NTFS format only.
Plugs in a USB device to upload Viewers (configured by
the VK6000) to the Control Box.
The LED blinks green to indicate that Viewers are being
uploaded, and lights green to indicate a successful
upload, with the buzzer beeping once upon USB plug-in
and once upon upload success.
The LED lights orange to indicate upload failure, with the
buzzer beeping 3 times for no available file found or
upload failure.
11 reset button
Clear all settings but network: Press and hold until
the front panel LEDs blink once, with the buzzer
beeping once (about 8 seconds). The LEDs and
buzzer will trigger once more when the reset is
complete.
Reset network settings: Short press once.
Note: For more reset functions, please refer to the user
manual.
12 Control Box ID
Switch
Use the switch to set an ID for the Control Box.
13 LCD panel and
buttons
Use the Up, Down, and Enter buttons to display the unit’s
system information, and set its ID.
14 power LED Lights green when the unit is turned on.
