VM0202H / VM0202HB User Manual
vi
Package Contents
Check to make sure that all the components are in working order. If you
encounter any problem, please contact your dealer.
VM0202H
1 VM0202H 4K HDMI Matrix Switch
1 IR remote control
1 IR receiver
1 power adapter
1 mounting kit
1 user instructions
VM0202HB
1 VM0202HB 2 x 2 True 4K HDMI Matrix Switch with Audio De-
Embedder
1 IR remote control
1 IR receiver
1 power adapter
1 3-pole terminal block
1 mounting kit
1 user instructions
