Aten PG95230 [6/136] Package contents

eco PDU PG Series User Manual

Package Contents

Check to make sure that all the components are in working order. If you

encounter any problem, please contact your dealer.

The eco PDU PG series standard package consists of:

1 3-Phase 30-Outlet 0U eco PDU unit

1 rack mount kit

1 RJ-45 to DB-9 cable

1 full-panel colored sticker

1 user instructions
