NRGence™ Remote Terminal Guide
2
Telnet
Telnet is available on all NRGence™ eco PDUs installed with the latest
firmware. You can log in to the eco PDU via Telnet from any computer
connected to the same network.
Setup
First, log in to the eco PDU’s web GUI, then select the Setup tab and click
Security from the menu bar. Under Working Mode, check Enable Telnet
Server and then click Save at the bottom of the page.
Note: If the Enable Telnet Server option is not available, please download the
latest firmware from our website: www.aten.com.
