Aten PE5108 [3/13] Logging in

NRGence™ Remote Terminal Guide

Logging In

To log in to the eco PDU via Telnet, do the following:

1. On your computer, open the start menu and select Run.

2. In the box type cmd and click OK.

3. At the command prompt, key in telnet and the IP Address of the PDU, as

follows:

telnet [IP Address]

4. Press Enter. The login screen appears:

5. At the login prompt, enter the default Username: teladmin; and Password:

telpwd.

Note: The Telnet username and password can be configured on the User tab

of the eco PDU's web GUI.

6. When the Telnet session is established, Logged in successfully appears

along with the command line prompt:
