S2989G-24TX Operation Manual Chapter 2 Layer 2 services

Configuration

2.22.3

MAC Notification Example

IP address of network management station (NMS) is 1.1.1.5, IP address of Agent is

1.1.1.9. NMS will receive Trap message from Agent. (Note: NMS may set the

authentication to the community character string of trap, suppose the community

character string as usertrap)

Configuration procedure in the following:

Switch(config)#snmp-server enable

Switch(config)#snmp-server enable traps mac-notification

Switch(config)# mac-address-table notification

Switch(config)# mac-address-table notification interval 5

Switch(config)# mac-address-table notification history-size 100

Switch(Config-If-Ethernet1/0/4)# mac-notification both

2.22.4

MAC Notification Troubleshooting

Check whether trap message is sent successfully by show command and debug

command of snmp.
