Nec MD302C6 [15/36] English

English-11

English

Controls

 Power On/Off

Press and hold the switch to turn on/off the display.

NOTE: Wait at least 10 seconds between on/off actions.

 MINUS button

Without displaying the OSD on the screen, press this button to switch the input source of  INPUT 1 to DisplayPort 1 or

 DVI 1. (This function is available only when “ENABLE FUNCTIONS” setting of the direct OSD menu setting is set to

With the OSD screen displayed, press this button to move the cursor to right/left or up/down.

 MENU button

Without displaying the OSD on the screen, press this button to switch the input port displayed on the screen. The input port

is switched in the following order: INPUT 1, INPUT 2, and Input 1 + Input 2.

(This function is available only when “ENABLE FUNCTIONS” setting of the direct OSD menu setting is set to “Enable

Switching Input Source” or “Enable Both Functions” (see page 26)).

Press and hold this button to show OSD setting menus.

With the OSD screen displayed, press this button to select and set OSD items.

 LCD Luminance Sensor

Caution: Do not touch the LCD luminance sensor. It may cause the set luminance level to change and/or the LCD to fail.

4 Blinking green On Calibrating

5 Orange On Power management on

6 Blinking orange On Advanced power management on

7 Red/blinking red On Error (Contact NEC technical support)

 Ambient Light Sensor
