English-2
Contents
Your new MD462OR box* should contain the following main components:
• OR Cabinet (incl. wall bracket x 1, display bracket x 2)
• LCD monitor MultiSync P463
• Power cord*
1
• Wireless Remote Control and AA Batteries
• MD462OR Installation and Maintenance Guide
• MD462OR Quick Reference Guide
• MultiSync P463 User’s Manual
• Medical Transformer (incl. jumper cable x 1)
• IR Sensor
OR Cabinet
Wall bracket
Medical
Transformer
Display bracket x 2
Wireless Remote Control
and AA Batteries
MD462OR Maintenance &
Installation Guide
MD462OR Quick Reference
Guide
P463 User's Manual
IR Sensor
* Remember to save your original box and packing material to transport or ship the monitor.
*
1
Type and number of power cords included will depend on the where the LCD monitor is to be shipped. When more than one
power cord is included, please use a power cord that matches the AC voltage of the power outlet and has been approved by
and complies with the safety standard of your particular country.
