Samsung 150T [11/34] Setting up your monitor
![Samsung 150T [11/34] Setting up your monitor](/views2/1983407/page11/bgb.png)
9
English
Windows
®
95
To determine the version of Windows
®
95 that your computer uses, right click on the “My
Computer” icon on the Windows desktop and select “Properties”. The version number can be
seen on the “General” section under “System:”. Follow the directions given below according
to the version of your Windows
®
95 operating system:
Version 4.00.950A
1
Click on
START
,
SETTINGS
,
CONTROL PANEL
,
DISPLAY SETTINGS
tab,
CHANGE DISPLAY TYPE
,
CHANGE
,
HAVE DISK
.
2
Type the diskette drive letter in the box and click
OK
.
Version 4.00.950B
1
Click on
START
,
SETTINGS
,
CONTROL PANEL
,
DISPLAY
,
ADVANCED
PROPERTIES
,
MONITOR
tab,
HAVE DISK
.
2
Type the diskette letter in the box and click
OK
.
Self-Test Feature Check (STFC)
Your monitor provides a self test feature that allows you to check whether your monitor is
functioning properly. If your monitor and computer are properly connected but the monitor
screen remains dark and the power indicator is blinking, run the monitor self-test by
performing the following steps:
1
Turn off both your computer and the monitor.
2
Unplug the video cable from the back of the computer.
3
Turn on the monitor.
Setting up Your Monitor
