Samsung 150T [19/34] Adjusting your fpd
![Samsung 150T [19/34] Adjusting your fpd](/views2/1983407/page19/bg13.png)
17
English
Language:
■
English
■
Deutsch
■
Español
■
Français
■
Italiano
■
Svenka
Language sets the OSM to display in one of five
languages.
The language chosen affects only the language of the
OSM. It has no effect on any software running on the
computer.
Miscellaneous
This menu provides access to special convenience
functions.
■ Menu Position
Each time the OSM opens it displays in the same
location on the screen. Menu Position controls that
location.
• H-Position
• V-Position
Menu Display
Time:
■ 5 Seconds
■ 10 Seconds
■ 20 Seconds
■ 200 Seconds
The OSM stays active for as long as it is in use. Menu
Display Time sets the length of time the OSM will
remain active after the last time you pushed a button.
Table 2. Screen controls (
Continued
)
Icon
Menus and
Sub-menus
Function Descriptions
– +
EXIT MENUAUTO EXIT MENUAUTO EXIT MENUAUTO EXIT MENUAUTO
EXIT MENUAUTO EXIT MENUAUTO EXIT MENUAUTO EXIT MENUAUTO
Adjusting Your FPD
