Omron CS2 Small Cuff (HEM-CS24) [2/6] D ring

CS2 Small cuff

Instructions for use

Instruction Manual for Small Cuff

Thank you for purchasing the OMRON Small Cuff.

Arm circumference for this cuff is 17 to 22 centi-

meters. OMRON Small Cuff can be connected to

various OMRON Blood Pressure Monitors. Please

refer to the original instruction manual of your Blood

Pressure Monitor.

Please check your present product as to which plug

you must use. Connect the correct air plug to the air

tube.

Applying the Arm Cuff

1. Put your left arm through the cuff loop.

Note: If the cuff is not assembled, pass the end

of the cuff furthest from the tubing through

the metal D-ring to form a loop. The smooth

cloth should be on the inside of the cuff loop.

2. Position the arm correctly.

1) The air tube should run down the inside of your

forearm and be in line with your middle ﬁnger.

2) The bottom of the cuff should be approximately

1 to 2 cm above your elbow.

3) Apply the cuff to your upper arm so that the

marker (arrow under tube) is centered on the

middle of your inner arm and points down the

inside of the arm.

Pile side material

Sewn hook material

D-ring

1 – 2 c m

Cuff

Air Plug (connects to Air Jack)

Air Tube

Pile side material

Sewn hook material

D-ring

1 – 2 cm

Please read this instruction manual thoroughly before using the unit.

Please keep for future reference.
