● The Dual control mode cannot be activated
when the air conditioner is in the front
defrosting mode “
”.
Automatic upper ventilator system:
1. Push the “CLIMATE” button to on.
2. Select the “Upper Vent” key and the
indicator on the screen will illuminate.
The air flow against the driver’s or pas-
senger’s upper body becomes gentle.
In this mode, air from the center ventilators
flows both straight and upward in order to
control the cabin temperature without blow-
ing air directly on the occupants.
Distribution between straight and upward flows
is determined automatically by the climate con-
trol system. If you prefer strong air flow against
your upper body, select “Upper Vent” key to
turn the indicator off.
When the outside temperature decreases to
approximately ⫺14°F (⫺10°C), the ⬙Upper Vent⬙
function will not activate. The ⬙Upper Vent⬙
function will reactivate automatically when am-
bient temperature is approximately ⫺14°F
(⫺10°C) or above.
Display Forest Air™ system setting screen :
The “Forest Air setting” screen will appear when
selecting the “Forest Air Setting” key.
For the details about the Forest Air™ system
setting operation, see “Setting Forest Air™”
later in this section.
Display Forest Air™ Information screen :
The Forest Air™ system information screen will
appear when selecting the “Forest Air Info” key.
For details about the Forest Air™ system infor-
mation screen, see “Forest Air™ system Infor-
mation” later in this section.
FOREST AIR™
The Forest Air™ system keeps the air inside the
vehicle clean using the automatic air intake
system and automatic ventilation. The Forest
Air™ system also makes the inside of the
vehicle more comfortable, using a combination
of the upper ventilator and center ventilators at
random.
*Forest Air™ is a trademark of Nissan Motor
Co., Ltd.
Main operation
Push the “ ” button.
(The “
” and “AUTO” indicator light on the
button will illuminate.)
When the following functions and sensors are
turned on, the Forest Air™ system settings will
activate.
– Breeze Mode
–
Outside odor and exhaust gas detection sensor
– Inside Air Quality sensor
– Auto humidity control
The fan speed and air flow is automatically set
to the AUTO position.
● The Forest Air™ system can be adjusted
and/or activated/deactivated for each func-
tion. For details of the Forest Air™ system
settings, see later in this section.
● When the “
” button is pushed while
the air conditioner is off, the air conditioner
will automatically activate.
● The Forest Air™ system automatically turns
off when the outside temperature is below
approximately 32°F (0°C). When the tem-
perature is below approximately 32°F (0°C),
the Forest Air system can not be turned on
when the
button is pressed. This is
not a malfunction. Push the
to reac-
tivate the system when the outside tempera-
ture is above approximately 32°F (0°C). The
Monitor, climate, audio, phone and voice recognition systems 4-39
