8
Restore default setting
Restore all settings of the TX to default settings.
NOTE: The matching setting will also be cleared
after restoring.
Version of the TX
Serial number
5 Battery Charger
Use the battery charger to recharge the battery
of VmicLink5 system.
The indicator turns red while the battery is
charging.
The indicator turns green while the battery has
been fully charged.
6 Specifications
VmicLink5 System
RF power 15dBm(30mW)
RF frequence 5725-5875MHz
Channel
3CH, RX channel changeable, TX follow
with RX
Transmission distance 30m with no obstacle
Interface
Transmitter Mic in: Max 160mV/-13dBu,
1.8V phantom power
Transmitter Line in: Max 2V/8dBu, 50V
DC isolation
Receiver Phone out: Max 70mW/32Ω,
10V DC isolation
Receiver Line out: 4 times mic in gain,
50V DC isolation
Receive sensitivity 98dB
THD+N -92dB
Sample rate 48K/16bit
Audio frequence
response
40Hz-18KHz/±1dB
Voice delay 18ms
Power consumption
RX: 180mA/6V
TX: 140mA/6V
Antenna gain 3dBi
Weight 810g
Battery 7.2V/1000mAh Li-ion
Battery type LP-E17(CANON EOS M3/750D/760D)
Dimensions
RX: 113x64x28mm
TX: 113x64x28mm
Operating
temperature
0°C-50°C
Storage temperature -20°C-55°C
