Saramonic VmicLink5RX+TX+TX+TX [7/12] Body pack transmitter vmiclink5 tx
![Saramonic VmicLink5RX+TX+TX+TX [7/12] Body pack transmitter vmiclink5 tx](/views2/1989511/page7/bg7.png)
5
NOTE: Please match the TX and RX if they
haven't been matched before.
Once RX and TX have been matched successfully,
the setting is retained even after the power is
turned off.
The RX and TX will automatically match with
each other everytime after powered on.
If use another TX, please match the RX with the
new TX.
When need to relieve TX and RX connection,
select and confirm "Restore default" menu.
Set backlight
Select ON, OFF or Delay 10 / 30 /60 seconds.
Default is "Delay 10s."
Restore settings
Confirm it then the parameters of RX are
restored to their factory default settings.
NOTE: The matching setting will also be cleared
after restoring.
Version of the RX
Serial number
4 Body-pack Transmitter VmicLink5-TX
The VmicLink5-TX is a compact transmitter that
employs a crystal-controlled PLL synthesizer. It is
equipped with a muting function and lock-type
Mic and Line input connectors.
4.1 Product Structure
①
Antennas
Screw clockwise to install.
Screw counterclockwise to dismantle.
Adjust the antennas accordingly to deliver the
best transmission.
②
Power / Mute button
Function Operation
Power ON Press button for one second or longer
Power OFF Press button until it turns off
Mute ON
Short press button
Mute OFF
③
SET button
Long press the SET button to enter the displayed
menu.
Then, short press the SET button to confirm your
option or long press again to exit without saving.
④ +
or – button
