![VOICE SYSTEMS CLUB MINI [21/34] Specifiche tecniche specifiche tecniche](/views2/1989524/page21/bg15.png)
VOICE SYSTEMS - CLUB MINI - MANUALE UTENTE
19
IITT
SSPPEECCIIFFIICCHHEE TTEECCNNIICCHHEE
SSPPEECCIIFFIICCHHEE TTEECCNNIICCHHEE
C LU B M I N I SY S T E M
C LU B M I N I SY S T E M
SATELLITE
SATELLITE
SUB
SUB
POWER HANDLING NOMINAL 350 Wa (EIAJ test - 1kHz, 1% THD) 700 Wa (EIAJ test - 1kHz, 1% THD)
FREQUENCY RESPONSE 80 Hz - 20 kHz 50 Hz - 90 Hz
INPUT SENSITIVITY 0 dBu 0 dBu
MAX SPL CALCULATED 120 dB 124 dB
CROSSOVER FREQUENCY 2800 Hz
SUBSONIC FILTER Yes
HF PROTECTIONS PTC, HPCCR bulb
ACTIVE PROTECTIVE CIRCUITRY thermal, overcurrent, non audio sig-
nals
NOMINAL INPUT IMPEDANCE 10 kOhm balanced to ground
WOOFER 8" 2 x 8"
Impedance 4 Ohm 2x4 Ohm
Magnet neodymium neodymium
Voice coil 2.5" aluminium 2.5" aluminium
Former kapton kapton
TWEETER 1"
Impedance 8 Ohm
Magnet ceramic
Voice coil aluminium
Diaphragm mylar
ANGULAR DISPERSION 90° x 60°
CONSTRUCTION
CABINET front: 15 mm laminated birch ply-
wood
front: 30 mm laminated birch ply-
wood
top, boom, rear, sides: 12 mm lam-
inated birch plywood
top, boom, rear, sides: 15 mm lami-
nated birch plywood
FINISH black scratch resistant paint black scratch resistant paint
PROTECTION metal grid metal grid
DIMENSIONS HXWXD MM 410x268x285 550x280x400
FLYING SYSTEM 2xM8 - top, boom, sides
1xM8 - rear
POLE MOUNT 1 boom 1 top
WEIGHT 8 Kg 16 Kg
CONTROL PANEL
Level from -Inf to 0 dB
Presets push selecon, 4 leds to sign the ac-
ve preset:
1) FLAT
2) D.BOOST
3) SPEECH
4) VOICE
Indicaon leds 1) green led = ON/OFF
2) green led = SIGNAL ON
3) yellow led = TEMPOUT
4) red led = CLIP
CONNECTIONS input signal: 1 Neutrik Speakon
NL4MP, 1+ IN+, 1- IN-
input signals: 2 XLR
power supply: AC socket
output signals: 2 Neutrik Speakon
NL4MP, 1+ OUT+, 1- OUT-
