VOICE SYSTEMS BEE-T.Five [12/44] Specifiche tecniche
![VOICE SYSTEMS BEE-T.Five [12/44] Specifiche tecniche](/views2/1989529/page12/bgc.png)
BEE Series – Compact Professional Speaker System
12
Specifiche Tecniche
BEE LIVE
BEE MAX
BEE STUDIO
BEE THEATRE
POTENZA
AMPLIFICATORE
(1kHz, THD 1%)
W IHF 90 W (90+30) W
(90+30) W
versione passiva 150W
DISTORSIONE (THD+N) < 0.1%
IMPEDENZA
di INGRESSO
kOhms
30 (balanced line) -15 (unbal line)
2 (balanced mic) - 1 (unbal mic)
SENSIBILITA'
di INGRESSO
dB
0 (0.775 V) Line
-30 dB Mic
ALIMENTAZIONE vedi targhetta informativa sull'apparato
SENSIBILITA'
(SPL 1W/1m)
dB 89 91 91
RISPOSTA
IN FREQUENZA
Hz (-10dB) 80-16000
70-20000 (Bee Max)
65-20000 (Bee Studio)
70-20000
DISPERSIONE (OxV) ° 60 x 60 90 x 60
MAX SPL dB 109 112
COMPONENTI 1x5" full range
Woofer da 5"
+ tweeter
a compressione
da 0,8"
2 Woofer da 4"
+ tweeter
a compressione
da 1"
COSTRUZIONE Materiale Composito ad alta resistenza.
CONTROLLI Hi Definition, Line level, Mic level, GND Lift .
CONNESSIONI
Mic input: 1 XLR -F, Line input: 1 XLR -F
Mix out, Link: 1 x Jack
DIMENSIONI mm (LxHxD)
182 x 330 x 226 182 x 330 x 226 182 x 330 x 226
PESO kg 4,2
4,4(Max
–4,6(Studio) 4,5
