VOICE SYSTEMS BEE-T.Five [42/44] Spécifications techniques
![VOICE SYSTEMS BEE-T.Five [42/44] Spécifications techniques](/views2/1989529/page42/bg2a.png)
BEE Series – Compact Professional Speaker System
42
Spécifications techniques
BEE LIVE
BEE MAX
BEE STUDIO
BEE
THEATRE
PUISSANCE
AMPLIFICATEUR
(1kHz, THD 1%)
W IHF 90 W (90+30) W
(90+30) W
passive version 150W
DISTORSION (THD+N) < 0.1%
IMPEDANCE
D’ENTREEE
Kohms
30 (balanced line) -15 (unbal line)
2 (balanced mic) - 1 (unbal mic)
SENSIBILITE
D’ENTREE
DB
0 (0.775 V) Line
-30 dB Mic
ALIMENTATION Voir étiquette d’information sur l’appareil
SENSIBILITE
(SPL 1W/1m)
DB 89 91 91
REPONSE EN
FREQUENCE
Hz (-10dB) 80-16000
70-20000 (Bee Max)
65-20000 (Bee Studio)
70-20000
DISPERSION ° 60 x 60 90 x 60
MAX SPL DB 109 112
ELEMENTS 1x5" full range
5” Woofer
+ 0,8”compression
tweeter
2x4” Woofers
+ 1” compression
tweeter
CONSTRUCTION Composite molded, high impact enclosure.
COMMANDES Hi Definition, Line level, Mic level, GND Lift .
CONNEXIONS
Mic input: 1 XLR -F, Line input: 1 XLR -F
Mix out, Link: 1 x Jack
DIMENSIONS mm (LxHxD) 182 x 330 x 226 182 x 330 x 226 182 x 330 x 226
POIDS Kg 4,2 4,4(Max –4,6(Studio) 4,5
