Shure BRH50M-LC [5/7] Specifications
![Shure BRH50M-LC [5/7] Specifications](/views2/1989607/page5/bg5.png)
6-Pin Headset ConnectorWireSignalContactConnector
6WhiteHeadphone Audio GroundSleeve
6.3 mm (1/4") TRS 5GreenHeadphone Audio 2 (boom side)Tip
4OrangeHeadphone Audio 1Ring
6-Pin Headset ConnectorWireSignal
1RedMic +
2BlackMic −
3Shield (uncoated)Mic Ground
4YellowHeadphone Audio 1
5OrangeHeadphone Audio 2 (boom side)
6WhiteHeadphone Audio Ground
Specifications
Weight
208 g (7.4 oz.), without cable
Environmental Conditions
18° to 60° C (0° to 140° F)Operating Temperature
-29° to 74° C (-29° to 165° F)Storage Temperature
0 to 95%Relative Humidity
Microphone
Type
Dynamic, Neodymium magnet
Polar Pattern
Supercardioid
Frequency Response
40 to 16,000 Hz
Output Impedance
250 Ω
Sensitivity
at 1 kHz, open circuit voltage
−60.0 dBV/Pa* (1.0 mV)
0
Polarity
Positive pressure on diaphragm produces positive voltage on pin 1 (red wire)
with respect to pin 2 (black wire).
Headphone
Transducer Type
Dynamic, Neodymium magnet
Driver Size
40 mm
Frequency Response
20 to 20,000 Hz
Sensitivity
@ 1 kHz
110 dB SPL/mW
Impedance
@ 1 kHz
300 Ω
Maximum Input Power
1000 mW
Find More Information Online
For more information, visit http://www.shure.com
0
*1 Pa = 94 dB SPL
Shure IncorporatedBRH50M Broadcast Headset
5/72017/10/23
