Scanner refers to a lighting instrument with a pan and tilt mirror; however, in the controller it can be used
to control any DMX-512 compatible device as a generic fixture.
Stand Alone refers to a fixture s ability to function independently of an external controller and usually in
sync to music, from a built in microphone.
Shutter is a mechanical device in the lighting fixture that allows you to block the lights path. It is often used
to lessen the intensity of the light output and to strobe.
Operating instructions
3.1
Setup
3.1.1 ting up the system
Plug the AC to DC power supply to the system back panel and to the mains outlet.
Plug in your DMX cable(s) to your intelligent lighting as described in the fixtures’ user manuals. For a
quick Primer on DMX see the “DMX Primer” section in the Appendix of this manual.
3.1.2 Fixture addressing
The DM-X10 is programmed to control 16 channels of DMX per fixture, therefore the fixtures you wish
to control with the corresponding FIXTURE buttons on the unit, must be spaced 16 channels apart.
Fixture
Default DMX
Start Address
Binary DIP
Switches Set to
"ON"
1
1
1
2
17
1, 5
3
33
1, 6
4
49
1, 5, 6
5
65
1, 7
6
81
1, 5, 7
7
97
1, 6, 7
8
113
1, 5, 6, 7
9
129
1, 8
10
145
1, 5, 8
11
161
1, 6, 8
12
177
1, 5, 6, 8
Please refer to your individual fixture s manual for DMX addressing instructions.
The table above refers to a standard 9 dipswitch binary configurable device.
3.1.3 Fade Time Assign
You can choose whether the board’s fade time during scene execution is implemented broadly to all
output channels or only to the Pan & Tilt movement channels. This is relevant because often you will
want gobos and colors to change quickly while not affecting the movement of the light.
Action :
1. Turn the DM-X10 power OFF
2. Hold the MODE and TAP DISPLAY buttons simultaneously and switch the power back ON
3. The DM-X10 is now in Fade Time Assign mode
4. Pressing the TAP DISPLAY button toggles between “ALL CH” and “ONLY X/Y”
5. ALL CH means that fade time affects all channels
6. ONLY X/Y means that fade time only affects pan and tilt functions
3.2
Operation
3.2.1 Manual Mode
The manual mode allows direct control of all fixtures. You are able to move them and change
