11
ENGLISH
SPECIFICATIONS
MODEL M 501 M 601 M 801 M 502 M 602
SYSTEM
IMPEDANCE 8 Ω 8 Ω 8 Ω 8 Ω 8 Ω
POWER (RMS) 80 W 100 W 150 W 100 W 120 W
POWER (peak) 320 W 400 W 600 W 400 W 480 W
RECCOMENDED AMPLIFIER 160 W 200 W 300 W 200 W 240 W
PROTECTION PTC DYN. ACTIVE MOSFET DYN. ACTIVE MOSFET DYN. ACTIVE MOSFET DYN. ACTIVE MOSFET
FREQUENCY RESPONSE
(–10 dB)
80 Hz ÷ 20 kHz 85 Hz ÷ 20 kHz 65 Hz ÷ 20 kHz 90 Hz ÷ 20 kHz 80 Hz ÷ 20 kHz
FREQUENCY RESPONSE
(– 3 dB)
110 Hz ÷ 13 kHz 115 Hz ÷ 20 kHz 95 Hz ÷ 20 kHz 120 Hz ÷ 20 kHz 125 Hz ÷ 20 kHz
HORIZONTAL DISPERSION 90° 90° 90° 90° 90°
VERTICAL DISPERSION 90° 90° 60° 90° 90°
SENSITIVITY (1 W, 1m) 87 dB 93 dB 93 dB 90 dB 95 dB
MAX. SOUND PRESSURE LEVEL (peak) 112 dB 119 dB 121 dB 116 dB 122 dB
CROSSOVER FREQUENCY 1.9 kHz 2.2 kHz 1.8 kHz 2.3 kHz 2 kHz
LOW FREQUENCY TRANSDUCERS
WOOFER TYPE 5.5” 7” 8.5” 2 x 5.5” 2 x 7”
WOOFER VOICE COIL 1.2” 1.2” 2” 1.2” 1.5”
WOOFER IMPEDANCE 8 Ω 8 Ω 8 Ω 16 Ω 16 Ω
WOOFER POWER
80 W (AES)
320 W (peak)
80 W (AES)
320 W (peak)
150 W (AES)
600 W (peak)
80 W (AES)
320 W (peak)
80 W (AES)
320 W (peak)
WOOFER SENSITIVITY 87 dB (1 W, 1 m) 92 dB (1 W, 1 m) 92 dB (1 W, 1 m) 88 dB (1 W, 1 m) 92 dB (1 W, 1 m)
HIGH FREQUENCY TRANSDUCERS
DRIVER TYPE 1.6” 1” 1” 1” 1”
DRIVER VOICE COIL 1” 1.4” 1.4” 1.4” 1.4”
DRIVER IMPEDANCE 8 Ω 8 Ω 8 Ω 8 Ω 8 Ω
DRIVER POWER
10 W (AES)
40 W (peak)
25 W (AES)
40 W (peak)
25 W (AES)
40 W (peak)
25 W (AES)
40 W (peak)
25 W (AES)
40 W (peak)
DRIVER SENSITIVITY 90 dB (1 W, 1 m) 106 dB (1 W, 1 m) 106 dB (1 W, 1 m) 106 dB (1 W, 1 m) 106 dB (1 W, 1 m)
PHYSICAL SPECS.
CABINET Trapezoidal (angle: 8°), made of MDF (12 mm)
THREADED INSERTS 6 x M6, 2 x M10 6 x M6, 2 x M10 8 x M6, 2 x M10 6 x M6, 2 x M10 8 x M6, 2 M10
COLOUR
black / white (
-W version)
GRILLE Steel, with a robust double mesh polyester clothing.
INPUT CONNECTORS 4-pin EUROBLOCK
DIMENSIONS (w, h, d) 175, 303, 185 mm 215, 359, 230 mm 261, 448, 282 mm 175, 470, 185 mm 215, 540, 230 mm
NET WEIGHT 5 kg (11 lb) 6.9 kg (15.18 lb) 9.7 kg (21.35 lb) 7.5 kg (16.5 lb) 11 kg (24.2 lb)
