Mackie 2404VLZ4 [36/40] Dimensions

VLZ4 4•Bus

Dimensions

6.0 in

153 mm

1.8 in

46 mm

29.4 in / 748 mm

19.1 in / 486 mm

6.0 in / 153 mm

WEIGHT

31.0 lb

14.1 kg

6.0 in

153 mm

1.8 in

46 mm

38.0 in / 964 mm

19.1 in / 486 mm

6.0 in / 153 mm

WEIGHT

39.0 lb

17. 7 kg
