WiFly NE1 Operation
delete or select “delete all lib” to delete all proles. Press the
DIAL/ENTER dial to enter.
4. Turn the DIAL/ENTER dial to select “Yes”. Press the DIAL/
ENTER dial to enter. Press the ESC/PAGE button to exit.
Patch Light Lib
1. Press and hold the SET-UP button for two seconds to enter
the main menu.
2. Turn the DIAL/ENTER dial to menu option 3 (Patch Light Lib).
Press the DIAL/ENTER dial to enter.
3. Turn the DIAL/ENTER dial to nd the prole that you wish to
patch. Press the DIAL/ENTER dial to enter.
4. Press the xture button(s), 1-12, that you wish to patch the
selected prole to and turn the DIAL/ENTER dial to set the
starting address. Press the DIAL/ENTER dial to enter. Press the
ESC/PAGE button to exit.
Delete Patch Light
1. Press and hold the SET-UP button for two seconds to enter
the main menu.
2. Turn the DIAL/ENTER dial to menu option 4 (Delete Light
Patch) then select the xture(s), 1-12, that you wish to delete
from the patch. Press the DIAL/ENTER dial to excute.
3. Turn the DIAL/ENTER dial to select “Yes”. Press the DIAL/
ENTER dial to excute.
Edit Light Lib
Note: WiFly NE1 allows for channel defaults to be set for PAN,
TILT, COLOR, and GOBO channels when the prole is being
created. If you wish to edit these defaults or set automatic de-
faults for other channels, this is where you do this.
1. Press the SET-UP button for two seconds to enter the main
ADJ Products, LLC www.adj.com - WiFly NE1 Page 11
WiFly NE1 Operation
LOADING FIXTURE PROFILES
NOTE: The WiFly NE1 comes pre-loaded with Generic xture
proles, which include RGB, RGBW, RGBA, RGBWA, RGB-
WAU, TRI-WHITE, 36CH 8-Bit ML (M1), and 36CH 16-Bit ML
(M2). See the Generic xture traits chart section on page 18 for
channel details. All other proles can be loaded from the USB
stick, which is included. The USB stick includes several ADJ
proles, which are compatible with this controller. Because the
le names are abbreviated, due to character limitations, please
us the “Fixture Prole Details” PDF list to cross reference the
les. So your controller runs at optimum speed, please only
load the proles that you will be using. A maximum of 65 pro-
les can be loaded at a time.
1. With the controllers power switch OFF, insert the included
USB drive into the controllers USB port and power ON the con-
troller.
2. Press and hold down the SET-UP button for two seconds to
enter the main menu.
3. Select menu option 1 (Load Light Lib) by pressing the DIAL/
ENTER dial then turn the DIAL/ENTER dial to nd the prole
that you wish to load.
4. Once you have located the prole, press the DIAL/ENTER
dial to load it. The display will momentarily read “Operation
Complete”. Repeat steps 3 and 4 to load additional proles or
press the ESC/PAGE button to exit.
Delete Light Lib
1. Press and hold the SET-UP button for two seconds to enter
the main menu.
2. Turn the DIAL/ENTER dial to menu option 2 (Delete Light
Lib). Press the DIAL/ENTER dial to enter.
3. Turn the DIAL/ENTER dial to nd the prole that you wish to
ADJ Products, LLC www.adj.com - WiFly NE1 Page 10
