Firmware Version

Note:This is a read only menu option that will display the con-

trollers current software version.

1. Press the SET-UP button for two seconds to enter the main

menu.

2. Turn the DIAL/ENTER dial to menu option 16 (Firmware Ver-

sion). Press the DIAL/ENTER dial to enter. Press the ESC/PAGE

button to exit.

Fixture Control, Saving, & Playing Memories

Note: Although the generic proles may work for you, it is rec-

ommended that you load and use the custom proles that were

provided on the USB sitck that was included with your control-

ler. The custom proles may oer you additional control and

features that the generic proles do not include. If you wish to

use the custom proles, please refer to the LOADING FIXTURE

PROFILES section of this user manual and load them before

proceeding. After you have patched your xtures, you can con-

trol and save memories using the following steps.

1. Press the FIXTURE button then select the xtures, using the

FUNCTION 1-12 buttons, that you want to control. If you are

using multiple xtures of the same type and want to control

them at the same time, you can press the rst and last buttons

so all xtures in between are selected at the same time. For ex-

ample, I have patched 6 xtures on buttons 1-6, to select them

all quickly, I would simultaneously press buttons 1 & 6 so all 6

xtures are selected.

2. Press the COLOR button and add a color by using the

FUNCTION 1-12 buttons. Turn the DIAL/ENTER dial to switch

between two pages of preset colors (Note: your xture must

support this feature to function).

3. Press the GOBO button and add a gobo by using the FUNC-

TION 1-12 buttons. Turn the DIAL/ENTER dial to switch be-

ADJ Products, LLC www.adj.com - WiFly NE1 Page 16

ADJ Products, LLC www.adj.com - WiFly NE1 Page 17

WiFly NE1 Operation

tween two pages of preset gobos (Note: your xture must sup-

port this feature to function).

4. Press the EFFECT button and add an eect by using the

FUNCTION 1-12 buttons. Turn the DIAL/ENTER dial to switch

between three pages of eects. In the display, you will see ML

EFFECT (for moving lights) and RGB EFFECT 1 and RGB EF-

FECT 2 (for RGBWA+UV LED’s) plus the speed, phase, size,

and direction settings, which can be controlled from the four

EFFECT rotary dials. You can pause an eect at any time by

pressing the PAUSE button. (Note: your xture must support

this feature to function).

5. Press the SHOW button and enable a show by using the

FUNCTION 1-12 buttons. (Note: your xture must support this

feature to function).

6. You can also set all channel values manually. If you have

already set your scene and want to store it. please see step 7

now. To make manual channel adjustments, press the FIXTURE

button, then press the DIAL/ENTER dial for two seconds, the

display will list channels 1-4 along with their current values.

Use the four EFFECT dials to adjust each channel listed in the

display. Channels are displayed four at a time. To access ad-

ditional channels, turn the DIAL/ENTER dial clockwise and

counter-clockwise.

7. To save your current output, press and hold down any of the

six MEMORY buttons until the display reads “Operation Com-

plete!”. Press that same MEMORY button a second time to

playback from that memory location, it should illuminate solid

green. Repeat steps 1-6 to store additional memories. There

are two memory banks. To access the secondary memory bank

press the ESC/PAGE button. If there is a memory running, that

MEMORY button will ash letting you know that is actively run-

ning in the other bank. If your memory includes an “EFFECT”,

you can pause the eect by pressing the PAUSE button.

WiFly NE1 Operation
