American DJ® - www.americandj.com - Quad Gem DMX™ Instruction Manual Page 7 American DJ® - www.americandj.com - Quad Gem DMX™ Instruction Manual Page 8
5-Pin XLR DMX Connectors.
Some manufactures use 5-pin XLR
connectors for DATA transmission in place of 3-pin. 5-pin XLR xtures
may be implemented in a 3-pin XLR DMX line. When inserting stan-
dard 5-pin XLR connectors in to a 3-pin line a cable adaptor must be
used, these adaptors are readily available at most electric stores. The
chart below details a proper cable conversion.
Conductor 5-Pin XLR Male (In)3-Pin XLR Female (Out)
Pin 1
Pin 5 - Do Not Use
Pin 4 - Do Not Use
Pin 3
Pin 2
Pin 1
Pin 3
Pin 2
Not Used
Not Used
Data True (+ signal)
Data Compliment (- signal)
Ground/Shield
3-Pin XLR to 5-Pin XLR Conversion
Quad Gem DMX™ Set Up Quad Gem DMX™ System Menu
ADDR - DMX Address Setting.
1. Tap the either the MENU, UP, or DOWN buttons until “ADDR”
is displayed, press ENTER.
2. “1” will now be displayed and ashing. Press the UP or
DOWN buttons to nd your desired address. Leave the display
on this address, and after a few seconds the address will be
saved into memory.
CHND - This will let you switch between 4 Channel DMX
mode and 7 Channel DMX mode.
1. Tap the either the MENU button until “CHND” is displayed,
press ENTER. Either “4 CH” or “7 CH” will be displayed
2. Tap the UP or DOWN buttons to choose your desired DMX
mode and press ENTER to conm and exit.
SLND - This will let you set unit as a master or slave in a
master/slave conguration.
1. Tap the either the MENU button until “SLND” is displayed,
press ENTER. “MSTR”, “SL 1” or “SL 2” will be displayed.
2. Tap the UP or DOWN buttons until your desired setting is
displayed, press ENTER to conm and exit.
SHND - in this mode you can choose your desired sound
active show or an preset program. Note: Only shows 4 & 6
are preset programs.
1. Tap the either the MENU button until “SHND” is displayed,
press ENTER. If you cannot nd this setting in the menu it
means that the unit is set as a “Slave”. The unit must be set as
a “Master” to choose a desired sound active show.
