©American Audio® - www.americanaudio.us - PXW 18P - Instruction Manual Page 10

Model: American Audio® PXW 18P - Professional Powered Subwoofer

Subwoofer Section:

Component: 18” Woofer (4 Ohm)

Dimensions: 35.4” x 28.7” x 29.1” / 900mm x 730mm x 740mm

Weight: 187.3 Lbs. / 85 kgs

Environmental conditions: Operational temperature: 5 to 35˚C (41 to 95˚F)

Operational humidity: 25 to 85% RH (non-condensation)

Storage temperature: -20 to 60˚C (4 to 140˚F)

Frequency Response: (-3dB) : 35Hz ~ 120Hz

Frequency Range: (-10dB) : 25Hz ~ 120Hz

Maximum SPL @ 1m: 128dB

Peak Output @ 1m: 134dB

Crossover Frequency: 120Hz (12dB/octave)

Input Type: Balanced Differential

Input Impedence: 50k

Input Protection: Level Protected

Thermal Protection: Input Stage Muting, Auto-Reset

Low-Frequency Tranducer Diameter: 18” (457mm)

Voice Coil Diameter: 4.0” (100mm)

Low-Frequency Power Amplifier: Rated Power* 800 Watts Continuous, 1000 Watts Peak

Rated THD: < 0.03%

Cooling: Passive-Heatsink with Speed Sensitive Electric Fan

NOTES:

The specifications are subject to change to any improvement by negotiations in advance.

The parts are subject to change to any improvement within the range of the specifications.

PXW 18P™ Technical Specifications
