American Audio Flex100 MP3 [23/30] Pitch adjustments

©American Audio® - www.AmericanAudio.us - Flex 100MP3 Instruction Manual Page 23

Figure 28

Figure 27

PITCH ADJUSTmENTS

1. PITCH SLIDER (7):

This function will increase or decrease the tracks playback speed or "PITCH."

The maximum pitch percentage manipulation in this function is +/-100%. The

pitch Slider (7) is used to decrease or increase the playback pitch. If the

slider is moved up (towards the top of the unit) the pitch will decrease, if the

slider is moved down (towards the bottom of the unit) the pitch will increase.

The pitch Slider (7) adjustment can be changed to range from +/-4%, +/-8%,

+/-16%, or +/-100% (See changing "PITCH SLIDER PERCENTAGE RANGE" on

the next page). This pitch adjustments will effect normal playback and loops only

when the pitch on/off Button (3) is turned on.

Using the Pitch Slider (7): Be sure the pitch function has been activated as

described above. To use the pitch Slider (7) slide the slider up and down.

Down will increase the pitch and up will decrease the pitch.

Activating the Pitch Slider (7): To activate the pitch Slider (7) you must

turn on the pitch adjustment function. Press the on/off Button (3) located

at the top right of the unit. The on/off Button (3) LED will glow when the

function is activated. If the pitch function is not activated the pitch Slider

(7) will not function.

PITCH ADJUSTmENTS:

You can activate the pitch Slider (7) by pressing the pitch on/off Button (3). When the button LED is lit,

the pitch Slider (7) is active and the pitch can be adjusted. The different pitch adjustments allow a track's or

a loop's playback speed to be manipulated. This speed manipulation is commonly used to beat match between

two or more music sources such as a turntable or another CD player. The playback speed may be increased or

decreased by a factor of +/-100. The next section details the different pitch manipulation schemes.

Figure 29
