LT-15A Rear Panel Controls and Features
Rear Panel:
1. BALANCED XLR/1/4” COMBO LINE INPUT – This connection is designed to accept a bal-
anced line input signal from a mixer or other line level device with a balanced output jack. Use a
balanced cable when the signal cable length exceeds 15 feet, this will reduce excessive signal
loss. Be sure to connect only line level input devices such as mixers and tape machines to this
jack.
2. XLR PARALLEL OUTPUT JACK – This jack is used to send the incoming line level signal from
either of the Line Level Inputs Jacks to another DLT-15A or other line level input jack such as
a mixer or power amp.
3. POWER LED - This LED will be lit when you switch on the power.
4. LOW CUT SWITCH -
5. LINE LEVEL INPUT VOLUME – This knob is used to regulate the output signal of the line level
source connected to the Line Level Input Jack (1).
TREBLE CONTROL – This knob is used to adjust the amount treble applied to the output sig-
nal. The maximum amount of treble gain is +15dB and the maximum amount of treble decrease
is -15dB. Turning the knob in a counter-clockwise direction will decrease the amount of treble
applied to a channel signal, turning the knob in a clockwise direction will increase the amount
of treble applied to a channel signal.
MIDRANGE CONTROL - This knob is used to adjust the midrange levels applied to the output
signal. The maximum amount of midrange gain is +12dB and the maximum amount of mid-
range decrease is -12dB. Turning the knob in a counter-clockwise direction will decrease the
amount of midrange applied to a channel signal, turning the knob in a clockwise direction will
increase the amount of midrange applied to a channel signal.
BASS CONTROL – This knob is used to adjust the amount bass applied to the output signal.
The maximum amount of bass gain is +15dB and the maximum amount of bass decrease is
-15dB. Turning the knob in a counter-clockwise direction will decrease the amount of bass ap-
plied to a channel signal, turning the knob in a clockwise direction will increase the amount of
bass applied to a channel signal.
6. VOLTAGE SELECTOR - Because power supplies vary from location to location we have in-
corporated a selectable voltage switch. This switch can select a voltage input of 120v~60Hz or
230v~50Hz. Always disconnect the power plug before changing the voltage.
7. MAIN POWER INLET – This connector is used to supply main power to the unit via the
included detachable power cord. The power connection uses an I.E.C. type connector, use
only the supplied polarized AC power cord. Use only a power cord that matches this type
of connection. Be sure to only connect this unit to a power outlet that matches the printed
power label on the unit. Never use a power when the ground prong has been removed or
broken o. The ground prong is used to reduce the risk of electrical shock in case of an elec-
trical short. This cord is designed to t in one direction only. Do not attempt to force a cord
if it does not t, be sure the cord is being inserted properly.
8. MAIN POWER SWITCH – This is the main power ON/OFF button. A green LED directly above
the power switch will glow indicating power is ON. Before main power is applied, be sure you
have made all connections to the speaker. Remember to avoid damaging pops to the speak-
ers, the mixer is turned on rst and turned o last.
