4 Electrical connection and operation

The mains voltage must correspond with

the voltage on the rating plate!

Switch (1.2) is an on/off switch. For continuous use

it can be engaged with the lateral locking button

(1.3). Pressing the switch again releases the lock.

Only ETS 150/3 EQ, ETS 150/5 EQ: See Fig. 3 for

connection and disconnection of the power cable.

5 Electronic control

The ETS 150/3 EQ, ETS 150/3 E, ETS 150/5

EQ, ETS 150/5 E has an electronic control

with which the rotational speed can be

varied step-free.

This allows the sanding speed to be adapted to the

optimum level according to the material concerned

(see Chapter 9). The speed is set using the rotary

control button (1.1).

6 Dust extraction

Dust extractors prevent large accu-mu-

lations of dust in the air in the working

environment and dirt collecting in the

workplace.

6.1 Inboard extraction

The machines are ﬁ tted with inbuilt extraction as

standard. The sanding dust is extracted through

suction openings in the sanding base (1.13) and

trapped in the turbo-ﬁ lter (1.5).The turbo-ﬁ lter

has to be changed when it is so full of dust that the

extraction power diminishes.

Inserting a turbo-ﬁ lter

- Push the front cardboard section of the turbo-

ﬁ lter with the sealing lip (1.4) onto the extraction

nozzle (1.9) of the ﬁ lter holder

- Insert rear cardboard section with slot (1.6) onto

the retaining strip (1.7) of the ﬁ lter holder

- Push the ﬁ lter holder with its opening (1.11) as

far as it will go onto the extraction nozzle (1.12)

of the machine and clamp tight by turning rotary

knob (1.10).

6.2 External extraction by an extraction

unit

In order to avoid frequent changing of the

turbo-ﬁ lter when carrying longer sanding jobs, it is

possible to connect a Festool extractor to the unit

instead of using inbuilt extraction.

In this case, the extraction pipe (Ø 27 mm (1.8))

of the extraction unit is connected to the suction

nozzle (1.12).

7 Choice and installation of the sanding

disks

7.1 Choice of sanding disk

The appliance can be ﬁ tted with three sanding disks

of different hardness depending on the surface to

be treated.

Hard: coarse sanding on surfaces, sanding at

edges.

Soft: universal for coarse and ﬁ ne sanding, for ﬂ at

and curved surfaces.

Super-soft: ﬁ ne sanding on formed parts, curves,

radii. Do not use on edges!

7.2 Assembly

The sanding disks and the tool-holding ﬁ xture on

the appliance are equipped with a positive holder

(2.1).

Make sure the sanding disk is correctly

positioned before screwing it tight.

For safety reasons, only use original Fes-

tool sanding disks!

8 Attaching sanding material

Always use original Festool sanding materials!

The appropriate Stickﬁ x sanding paper and Stick-

ﬁ x sanding felt can be fastened quickly and easily

onto the Stickﬁ x sanding base. The self-adhesive

sanding material (1.14) is simply pressed onto the

sanding base (1.13) and held safely in place by the

Stickﬁ x sanding base velcro surface. After use, the

StickFix sandpaper is simply pulled off.

9 Operating instructions

Never overload the tool by using too much

pressure!

The best sanding results are achieved when ap-

plying moderate pressure. The ETS 150/3 EQ, ETS

150/3 E gives the best surface quality and low

abrasion. The ETS 150/5 EQ, ETS 150/5 E provides

high abrasion with good surface quality. The sand-

ing performance and quality depend mainly on

the choice of the right sanding material. Festool

offers the appropriate sanding material for all ap-

plications (seeFestool catalogue or on the Internet

under “www.festool.com”).

We recommend the following settings on the ro-

tary control (1.1) for electronic machines:

rotary control setting

- sanding work

5 - 6

- sanding with max. drive

- sanding old paint
