32 XENYX CONTROL1USB Quick Start Guide 33
Specications
Frequency Response
Line-Level Inputs and Outputs
¼" jack, balanced or unbalanced 10 Hz to 40 kHz (+0 dB / -1 dB)
Phono input 20 Hz to 20 kHz (±1 dB)
Distortion (THD & IMD)
Line-level inputs to line-level outputs (unity gain) <0.01%, 20 Hz to 20 kHz @ +4 dBu
Phono input <0.10%, 20 Hz to 20 kHz @ +4 dBu
Noise Floor
Unity gain with Input 1, 2 and 3 assigned -86 dBu, 20 Hz to 20 kHz
Monitor A, B and C outputs, studio output, DAW, 2-Track A & B outputs -90 dBu, 20 Hz to 20 kHz
Phono input -75 dBu, 20 Hz to 20 kHz
Equivalent input noise (E.I.N.) -119 dBu, 20 Hz to 20 kHz
Dynamic Range
Line inputs 107 dB
Phono input 88 dB
Crosstalk
Adjacent inputs 95 dB @ 1 kHz
Left to right / right to left 85 dB @ 1 kHz
Muted / level o 95 dB @ 1 kHz
Control Range
Input level ±10 dB
Output level -12 dB to 0 dB
Dim switch 0 dB / -20 dB
Rated Input Voltage
Line inputs (+4 dB level setting) +4 dBu / +30 dBu (nominal/maximum)
Line inputs (-10 dB level setting) -10 dBu / +15 dBu (nominal/maximum)
Phono input @ 1 kHz, nominal gain 5 mV / 90 mV (nominal/maximum)
Rated Output Voltage
All line-level outputs (+4 dB level setting) +4 dBu / +21 dBu (nominal/maximum)
All line-level outputs (-10 dB level setting) -10 dBu / +8 dBu (nominal/maximum)
Maximum Voltage Gain
Input 1, 2 and 3 to:
Monitor A, B and C outputs +32 dB
DAW, 2-Track A & B, and phones (rear) outputs +22 dB
Studio output 32 dB
Phones 1 & 2 outputs 32 dB (output loaded @ 100 kΩ)
Monitor Mix Input to:
Phones (rear) outputs 12 dB
Studio output 22 dB
Phones 1 & 2 outputs 22 dB (output loaded @ 100 kΩ)
Phono input @ 1 kHz to:
Monitor A, B and C outputs 65 dB
DAW, 2-Track A & B, and phones (rear) outputs 55 dB
Studio output 66 dB
Phones 1 & 2 outputs 66 dB (output loaded @ 100 kΩ)
Input Impedance
Line input 20 kΩ balanced / 14 kΩ unbalanced
Phono input 40 kΩ
Output Impedance
Line output 200 Ω balanced / 100 Ω unbalanced
Headphone output 50 Ω
Input/Output VU Meters
12-segment LED CLIP, +10, +7, +4, +2, 0, -2, -4, -7, -10, -20, -30 dB
Talkback Section
Automatic gain control (AGC) Yes
Nominal output level +4 dBu (+4 dB output level setting)
Output level range -∞ to +10 dB
Power Supply / Voltage (Fuses)
Mains voltage 100 – 240 V~, 50/60 Hz
Fuse 100 – 240 V~, T 1AH 250 V
Power consumption max.15 W
Mains connection Standard IEC receptacle
USB
Audio Stereo in / out
Connector Type B
Sample rate 44.1 kHz, 48 kHz
Dimensions/Weight
Dimensions (H x W x D) 3.4 x 15.4 x 8" / 87 x 390 x 203 mm
Weight 5.1 lbs / 2.3 kg
