DIMENSIONAL SKETCHES
R
165.0mm
(R6.50”)
1
02.0mm
(4.02”)
R300.0mm
(
R11.81”)
155.0mm
(6.10”)
162.0mm
(6.38”)
240.7mm
(9.47”)
7°
