©American DJ® - www.americandj.com - Micro 3D Instruction Manual Page 9 ©American DJ® - www.americandj.com - Micro 3D Instruction Manual Page 10

Fixture Cleaning: Due to fog residue, smoke, and dust cleaning

the internal and external lenses should be carried out periodically to

optimize light output.

1. Use normal glass cleaner and a soft cloth to wipe down the out-

side casing.

2. Clean the external optics with glass cleaner and a soft cloth every

20 days.

3. Always be sure to dry all parts completely before plugging the

unit back in.

Cleaning frequency depends on the environment in which the fixture

operates (I.e. smoke, fog residue, dust, dew). In heavy use we recom-

mend cleaning on a monthly basis. Periodic cleaning will ensure lon-

gevity, and crisp beam output.

Micro 3D Cleaning

Micro 3D Trouble Shooting

Trouble Shooting: Listed below are a few common problems that

you may encounter, with solutions.

No laser output from the unit;

1. Be sure you have connected your unit into a standard wall

outlet.

2. Be sure that the unit is not in blackout mode.

3. In cold temperature situations it might take the laser a little longer

to produce output. It can take up to 3-5 minutes for the laser to

produce a beam. This is due to the laser diode which is very sen-

sitive.

Unit does not respond to sound;

1. Low frequencies (bass) should cause the unit to react to sound.

Tapping on the microphone, quiet or high pitched sounds may

not activate the unit.

Micro 3D Laser Remote Reset

Follow these simple instructions to reset your remote code.

Erase Remote Code:

Using a small pointy utensil, carefully press and hold the white

button (2), while doing this the indicator light (1) will glow for about 5

seconds then turn o. Once the indicator light turns o release the

button (2).

Activating and Linking Remote:

This action will set the code to link the laser to your remote. You can

link more then one laser to a remote.

Using a small pointy untensil, carefully press the white button (2)

and then press any button on the remote control. After pressing the

button on the remote control the indicator light (1) will ash 4 times.

Try to control the unit with the remote. If the unit can be controlled,

setting the code was successful. If it does not control the unit, try

agin.
