TURBOSOUND M15B [2/24] Important safety instructions
![TURBOSOUND M15B [2/24] Important safety instructions](/views2/1990940/page2/bg2.png)
2Milan Series
Terminals marked with this
symbol carry electrical
current of sufficient
magnitude to constitute risk of electric
shock. Use only high-quality
commercially-available speaker cables
with plugs pre-installed. All other
installation or modification should be
performed only by qualified personnel.
This symbol, wherever it
appears, alerts you to the
presence of uninsulated
dangerous voltage inside the
enclosure - voltage that may be
sufficient to constitute a risk of shock.
This symbol, wherever it
appears, alerts you to
important operating and
maintenance instructions in the
accompanying literature. Please read
the manual.
Caution
To reduce the risk of electric
shock, do not remove
the top cover (or the rear section).
No user serviceable parts inside.
Refer servicing to qualified personnel.
Caution
To reduce the risk of fire
or electric shock, do not
expose this appliance to rain and
moisture. The apparatus shall not
be exposed to dripping or splashing
liquids and no objects filled with
liquids, such as vases, shall be placed
on the apparatus.
Caution
These service instructions
are for use by qualified
service personnel only. To reduce the
risk of electric shock do not perform
any servicing other than that contained
in the operation instructions. Repairs
have to be performed by qualified
service personnel.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus
near water.
6. Clean only with dry cloth.
7. Do not block any ventilation
openings. Install in accordance with
the manufacturer’s instructions.
8. Do not install near any
heat sources such as radiators,
heat registers, stoves, or other
apparatus (including amplifiers)
that produce heat.
9. Do not defeat the safety purpose of
the polarized or grounding-type plug.
A polarized plug has two blades with
one wider than the other. A grounding-
type plug has two blades and a third
grounding prong. The wide blade or
the third prong are provided for your
safety. If the provided plug does not fit
into your outlet, consult an electrician
for replacement of the obsolete outlet.
10. Protect the power cord from being
walked on or pinched particularly
at plugs, convenience receptacles,
and the point where they exit from
the apparatus.
11. Use only attachments/accessories
specified by the manufacturer.
12. Use only
with the cart,
stand, tripod,
bracket, or table
specified by the
manufacturer,
or sold with
the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination
to avoid injury from tip-over.
13. Unplug this apparatus during
lightning storms or when unused
for long periods of time.
14. Refer all servicing to qualified
service personnel. Servicing is required
when the apparatus has been damaged
in any way, such as power supply cord
or plug is damaged, liquid has been
spilled or objects have fallen into the
apparatus, the apparatus has been
exposed to rain or moisture, does not
operate normally, or has been dropped.
15. The apparatus shall be connected
to a MAINS socket outlet with a
protective earthing connection.
16. Where the MAINS
plug or an appliance
coupler is used as the
disconnect device,
the disconnect
device shall remain
readily operable.
TECHNICAL SPECIFICATIONS AND
APPEARANCES ARE SUBJECT TO
CHANGE WITHOUT NOTICE AND
ACCURACY IS NOT GUARANTEED.
BEHRINGER, KLARK TEKNIK, MIDAS,
BUGERA, AND TURBOSOUND
ARE PART OF THE MUSIC GROUP
(MUSIC-GROUP.COM).
ALL TRADEMARKS ARE THE
PROPERTY OF THEIR RESPECTIVE
OWNERS. MUSIC GROUP ACCEPTS
NO LIABILITY FOR ANY LOSS
WHICH MAY BE SUFFERED BY
ANY PERSON WHO RELIES EITHER
WHOLLY OR IN PART UPON ANY
DESCRIPTION, PHOTOGRAPH OR
STATEMENT CONTAINED HEREIN.
COLORS AND SPECIFICATIONS MAY
VARY FROM ACTUAL PRODUCT.
MUSIC GROUP PRODUCTS ARE
SOLD THROUGH AUTHORIZED
FULLFILLERS AND RESELLERS ONLY.
FULLFILLERS AND RESELLERS ARE
NOT AGENTS OF MUSIC GROUP
AND HAVE ABSOLUTELY NO
AUTHORITY TO BIND MUSIC GROUP
BY ANY EXPRESS OR IMPLIED
UNDERTAKING OR REPRESENTATION.
THIS MANUAL IS COPYRIGHTED.
NO PART OF THIS MANUAL MAY BE
REPRODUCED OR TRANSMITTED
IN ANY FORM OR BY ANY MEANS,
ELECTRONIC OR MECHANICAL,
INCLUDING PHOTOCOPYING
AND RECORDING OF ANY KIND,
FOR ANY PURPOSE, WITHOUT THE
EXPRESS WRITTEN PERMISSION OF
MUSIC GROUP IP LTD.
ALL RIGHTS RESERVED.
© 2013 MUSIC Group IP Ltd.
Trident Chambers, Wickhams Cay,
P.O. Box 146, Road Town, Tortola,
British Virgin Islands
For the applicable warranty
terms and conditions and
additional information regarding
MUSIC Group’s Limited Warranty,
please see complete details online at
www.music-group.com/warranty.
Important Safety
Instructions
LEGAL DISCLAIMER
LIMITED WARRANTY
