1. Power Input: If you do not want to use a computer in your setup (i.e., if you are using

Trigger Finger Pro to control an external MIDI module), connect this input to a power

outlet using an optional power adapter (6V DC, 1A, center-positive, sold separately). You

do not need this connection when using Trigger Finger Pro with a computer; it will be

2. Power Switch: Press this button to power Trigger Finger Pro on or off.

3. USB Port: Use a standard USB cable to connect this USB port to your computer. The

computer's USB port provides ample power to Trigger Finger Pro. This connection is also

used to send and receive MIDI data to and from your computer.

4. MIDI Out: Use a standard five-pin MIDI cable to connect this MIDI Out to the MIDI In of

an external MIDI device (e.g., a synthesizer, sequencer, drum machine, etc.).

5. Display: Use this LCD to view Trigger Finger Pro's menus, options, parameters, and

settings.

6. Value Dial (Push to Enter): Use this dial to change the Preset, parameter values, settings,

etc. Pressing the dial also functions as an Enter button.

7. Function Buttons: Press these buttons to execute the command shown right above it in

the display.

8. Save: Press this button to save the current Preset, Sequence, Preferences, or all three.

Tip: Press and hold this button for two seconds to perform an automatic Save All. This

saves your Presets, Sequences, and Preferences all at once.

9. Assignable Knobs: Use these 360º knobs to send MIDI CC messages to your software

or external MIDI device. Alternatively, you can set the knobs to communicate with your

software using the Mackie Control or HUI protocols or to communicate with Arsenal. See

Working with Presets: Assignable Controls for more information.

In Pad Mode and Sequence Mode, use these knobs to adjust the parameters shown right

above them in the display.
