10. Assignable Faders: Use these faders to send MIDI CC messages to your software or

external MIDI device. Alternatively, you can set the faders to communicate with your

software using the Mackie Control or HUI protocols or to communicate with Arsenal. See

Working with Presets: Assignable Controls for more information.

11. Assignable Buttons: Use these buttons to send MIDI CC messages or Program Change

messages to your software or external MIDI device. They can function as momentary,

toggle (latching), or single-message buttons. Alternatively, you can set the buttons to

communicate with your software using the Mackie Control or HUI protocols or to

communicate with Arsenal. See Working with Presets: Assignable Controls for more

information.

12. Control Bank: Press this button to cycle through the four independent banks of

Assignable Knobs, Assignable Faders, and Assignable Buttons. The current control

bank letter (A–D) will appear in the display. All 12 physical controls will always be in the

same bank (e.g., you cannot adjust a knob in Control Bank A and a fader in Control Bank

B simultaneously).

Press and hold this button to see an overview of the control mapping (MIDI, Mackie

Control, HUI, or Arsenal) for the entire control bank. Use the assignable buttons to

select the control bank you are viewing.

13. Pads: Use these pads to trigger drum hits or other samples in your software or external

MIDI sound module. The pads are pressure- and velocity-sensitive, which makes them

very responsive and intuitive to play.

14. Pad Bank: Press this button to cycle through the four independent banks of pads. The

current pad bank letter (A–D) will appear in the display.

Press and hold this button to access the pads' secondary functions:

• Press Pad 1, 2, 3, or 4 to directly select Pad Bank A, B, C, or D (respectively).

• Press and hold Pad 9, 10, 11, or 12 to mute or unmute Pad Bank A

, B, C, or D

(respectively) in the current Sequence. This is essentially a momentary mute feature

for each pad bank.

• Press Pad 13, 14, 15, or 16 to mute or unmute Pad Bank A, B, C, or D (respectively)

in the current Sequence. This is essentially a toggle (latching) mute feature for each

pad bank.
