EN -14-
• Your fridge is designed to operate in the ambient
temperature intervals stated in the standards, ac-
cording to the climate class stated in the information
label. We do not recommend operating your fridge
out of stated temperatures value limits in terms of
cooling effectiveness.
• This appliance is designed for use at an ambient
temperature within the 10°C - 43°C range.
Note:
This appliance is designed to work at 43
o
C ambient temperature with no problem. Below -5
o
C ambient temperature, do not use refrigerator compartment as the foods that you put into
there will freeze. You can continue using freezer compartment.
Climate class Ambient (
o
C)
T 16 to 43 (
o
C)
ST 16 to 38 (
o
C)
N 16 to 32 (
o
C)
SN 10 to 32 (
o
C)
Accessories
Chiller Shelf
Keeping food in the Chiller compartment instead of
the freezer or refrigerator compartment allows food to
retain freshness and avour longer, while preserving its
fresh appearance. When the chiller tray becomes dirty,
remove it and wash it with water.
(Water freezes at 0°C, but foods containing salt or sugar
freeze at temperatures lower than that)
Normally the chiller compartment is used to store raw
sh, lightly pickled food, rice, etc...
Do not put foods you want to freeze or ice trays onto the chiller shelf.
Icematic
• Take out the ice making tray
• Fill the water to the line.
• Place the ice making tray in its original
position
• When ice cubes are formed, twist the lever
to drop ice cubes into the icebox.
Note:
• Do not ll the icebox with water to make ice. This may damage it.
• The movement of the ice maker may be difcult while the refrigerator is running. In such
a case it should be cleaned by removing the glass shelves.
Removing the Ice maker
• Remove the freezer glass shelves
• Remove the icemaker by pulling left or
right on the shelf.
You can remove the icemaker to increase the
available volume in the freezer compartment.
(Making ice cubes)
