Ultimate PVR with HD Digital Jukebox

4.2 Audio/Video Setting

This section indicates the A/V (Video or Audio) settings. Press SETUP button on the remote controller and

select the A/V.

This screen allows you to adjust the A/V settings of your TViX to your personal taste. Select

menu to

exit this SETUP. Press ‘NEXT’ button to change next setting.

Analog Audio output (Analog PCM) : Select this when you connect the audio with a stereo RCA

cable (the Red and White cable)

Digital Audio output (Digital RAW ) : Select this when you connect the audio with an coaxial/optical

cable for digital audio connection to the Decoder/Amplifier.

HDMI Audio : Select ON when you want to hear the audio from HDMI.

Dynamic Range Control : We recommend you to set the "DRC mode" to "Off", otherwise you could

not hear the sufficient sound (Volume Level Option).

ideo Output : Select this when you connect the video through a composite or HDMI cable. With

HDMI setting, you can select the output resolution among NTSC,PAL, 720p 50hz/60hz, 1080i

50hz/60hz. Setting it to 1080i will work on all HD grade TVs.

Aspect Ratio : 4:3 Letter Box / 4:3 Pan & Scan for ordinary TVs; 16:9 for Wide TVs, such as HDTV

or Plasma TV.

If the ratio of the TV is 4:3, select the 4:3 letter box or 4:3 Pan & Scan. If the ratio is 16:9, select 16:9.

* The 4:3 Letter box can show the original ratio of the multimedia file in 16:9.
