Maintenance

Cleaning the machine

To keep your sewing machine operating well, clean it often. No lubrication (oiling) is needed.

Wipe the exterior surface of your machine with a soft cloth to remove any dust or lint built up.

Wipe the screen with a clean, soft and damp cloth.

Cleaning the bobbin area

Note: Raise the needle, lower the feed dogs and

turn off the machine.

Remove the presser foot. Push the bobbin cover

release button (A) to the right and remove

the bobbin cover (B) and the bobbin. Use the

screwdriver to remove the two screws (C) in the

stitch plate. Lift up the stitch plate.

Clean the feed dogs and the bobbin area with the

brush found with the accessories.

Cleaning under the bobbin area

Clean the area under the bobbin case after

sewing several projects or any time you notice an

accumulation of lint in the bobbin case area.

Remove the bobbin case by lifting it up and to the

right. Clean the area with the brush or with a dry

cloth.

Put the bobbin case back into the hook race so that

WKHWLSÀWVLQWRWKHVWRSSHU'

Note: Do not blow air into the bobbin case area. The

dust and lint will be blown into your machine.

Replacing the stitch plate

With the feed dogs lowered, replace the stitch plate

and insert and tighten the two stitch plate screws.

Replace the bobbin cover.

Tip! Inserting the

screwdriver at the back

of the bobbin case will

help lift it up and make

it easier to remove.
