![Sony SLV-GA59 [4/4] Specifications](/views2/1029393/page4/bg4.png)
Additional Information
Warning
To prevent fire or shock hazard, do not expose the
unit to rain or moisture.
To avoid electrical shock, do not open the cabinet.
Refer servicing to qualified personnel only.
The mains lead must only be changed at a
qualified service shop.
Precautions
Safety
• This unit operates on 110 – 240 V AC,
50/60 Hz. Check that the unit’s operating
voltage is identical with your local power
supply.
• If anything falls into the cabinet, unplug the
unit and have it checked by qualified
personnel before operating it any further.
• The unit is not disconnected from the mains as
long as it is connected to the mains, even if the
unit itself has been turned off.
• Unplug the unit from the mains if you do not
intend to use it for an extended period of time.
To disconnect the lead, pull it out by the plug,
never by the lead.
Installing
• Allow adequate air circulation to prevent
internal heat buildup.
• Do not place the unit on surfaces (rugs,
blankets, etc.) or near materials (curtains,
draperies) that may block the ventilation slots.
• Do not install the unit near heat sources such
as radiators or air ducts, or in a place subject to
direct sunlight, excessive dust, mechanical
vibration or shock.
• Do not install the unit in an inclined position.
It is designed to be operated in a horizontal
position only.
• Keep the unit and cassettes away from
equipment with strong magnets, such as
microwave ovens or large loudspeakers.
• Do not place heavy objects on the unit.
• If the unit is brought directly from a cold to a
warm location, moisture may condense inside
the unit and cause damage to the video head
and tape. When you first install the unit, or
when you move it from a cold to a warm
location, wait for about four hours before
operating the unit.
Caution
Television programmes, films, video tapes, and
other materials may be copyrighted. Unauthorized
recording of such material may be contrary to the
provisions of the copyright laws. Also, use of this
recorder with cable television transmission may
require authorization from the cable television
transmitter and/or programme owner.
Compatible colour systems
• Check the colour systems of your unit using
the table below.
Model name
SLV-GA55MKII/
GA65MKII/
GA45AV
SLV-GA35MKII
SLV-GA59
Recording of video sources based on other
colour systems cannot be guaranteed.
• To play back tapes recorded with the PAL and
MESECAM colour systems, you need a TV or
colour monitor compatible with these systems.
• Tapes recorded with the NTSC colour system
can be played back on this unit using a TV or a
colour monitor for the PAL colour system.
Recording
PAL
MESECAM
NTSC 4.43
NTSC 3.58
PAL
MESECAM
NTSC 4.43
NTSC 3.58
Playback
PAL
MESECAM
NTSC 4.43
NTSC 3.58
PAL
MESECAM
NTSC 4.43
PAL
MESECAM
NTSC 4.43
NTSC 3.58
SECAM
Colour system
Specifications
System
Colour system
PAL, MESECAM, NTSC 4.43
NTSC 3.58 (SLV-GA55MKII, GA65MKII, GA45AV
and GA59 only)
SECAM (SLV-GA59)
RF output signal
(SLV-GA35MKII, GA55MKII, GA65MKII and GA59
only)
UHF channels 30 to 39
(B/G, D/K)
Aerial out
(SLV-GA35MKII, GA55MKII, GA65MKII and GA59
only)
75-ohm asymmetrical aerial socket
Inputs and outputs
LINE IN (SLV-GA55MKII, GA65MKII, GA45AV
and GA59 only)
VIDEO IN, phono jack (1)
Input signal: 1 Vp-p, 75 ohms,
unbalanced, sync negative
AUDIO IN, phono jack (1)
Input level: 327 mVrms
Input impedance: more than 47 kilohms
LINE OUT
VIDEO OUT, phono jack (1)
Output signal: 1 Vp-p, 75 ohms,
unbalanced, sync negative
AUDIO OUT, phono jack (1)
Standard output: 327 mVrms
Load impedance: 47 kilohms
Output impedance: less than 10 kilohms
General
Power requirements
110 – 240 V AC, 50/60 Hz
Power consumption
10 W (SLV-GA35MKII)
12 W (SLV-GA55MKII, GA65MKII, GA45AV
and GA59 only)
Operating temperature
5°C to 40°C
Storage temperature
–20°C to 60°C
Dimensions
Approx. 355 × 96 × 293 mm (w/h/d)
including projecting parts and controls
Mass
Approx. 3.8 kg
Supplied accessories
Remote commander (1)
R6 (Size AA) batteries (2)
Aerial cable (1) (SLV-GA35MKII, GA55MKII, GA65MKII
and GA59)
Plug adaptor (included in some models)
Audio/video cable (2-phono to 2-phono) (1) (SLV-
GA45AV only)
Design and specifications are subject to change without
notice.
PowerPlaybackRecording*Others
• Normal picture • Rough picture • Unclear picture • No picture (or
black & white
screen appears)
Sapphire tape cleaner
The unit incorporates a sapphire tape cleaner which cleans a video tape when it
is loaded. This cleaner can prevent the video heads from contamination by
removing dust or mold from a tape with its sapphire edge.
Head Condition Sensor
The Head Condition Sensor checks the conditions of video heads. If the heads
are dirty, a message will instruct you to insert a video head cleaning cassette.
Be sure to use the Sony T-25CLD, T-25CLW or E-25CLDR video head cleaning
cassette. If these cleaning cassettes are not available in your area, have the heads
cleaned at your nearest Sony Service facility (a standard service charge will be
required).
Troubleshooting
If you have any questions or problems not covered below, please consult your nearest Sony
service facility.
Symptom
The ?/1 ON/STANDBY switch does
not function.
The power is turned on but the
unit does not operate.
The unit enters standby mode
or turns off automatically.
The playback picture does not
appear on the TV screen.
The picture is not clear.
The picture rolls vertically
during picture search.
The picture has no sound.
The tape starts playing as soon
as it is inserted.
The tape is ejected when you
press z REC.
Nothing happens when you
press z REC.
A tape cannot be inserted.
The remote commander does
not function.
The unit needs to be cleaned.
The indicator lights on the unit are flashing.
The RESOLUTION CONTROL III
menu appears automatically.
* SLV-GA55MKII/GA65MKII/GA45AV and GA59 only
Auto head cleaner
The unit incorporates an auto head cleaner which cleans the video heads when
a tape is loaded or unloaded. When the heads are not sufficiently clean, even
after a tape has been loaded/unloaded several times, use a video head cleaning
cassette.
Symptoms caused by contaminated video heads
Remedy
• Connect the mains lead securely.
• Moisture condensation has occured. Turn the power
off, unplug the mains lead and leave the unit to dry
for over four hours.
• The auto safety system is triggered to protect your
tape and the unit’s mechanism when there is
something wrong with the tape or when the
mechanism is overloaded. Press ?/1 ON/STANDBY
to restart the unit. If the unit does not work after
pressing ?/1 ON/STANDBY again, disconnect the
mains lead from the mains. Wait for at least 15
seconds. Then reconnect the mains, and press
?/1 ON/STANDBY again. If the unit still does not
work, please consult your nearest Sony service
facility.
• Make sure the TV is set to the video channel. If you
are using a monitor, set it to video input.
• Adjust the tracking with the V/v TRACKING
NORMAL/SLOW/STILL ADJUST buttons.
• Make sure the COLOR SYSTEM switch is set to the
position corresponding to the colour system which
the tape was recorded with.
• The video heads are dirty (see below). Clean the
video heads using the Sony T-25CLD, T-25CLW or
E-25CLDR video head cleaning cassette. If these
cleaning cassettes are not available in your area, have
the heads cleaned at your nearest Sony service facility
(a standard service charge will be required). Do not
use a commercially available liquid type cleaning
cassette, as it may damage the video heads.
• If a message appears, this indicates that the Head
Condition Sensor has detected dirty video heads.
Follow the on-screen message.
• The video heads may have to be replaced. Consult
your local Sony service facility for more information.
• Adjust the vertical hold control on the TV or monitor.
• The tape is defective.
• If you made A/V connections, check the audio cable
connection.
• The safety tab has been removed. To record on this
tape, cover the tab hole.
• Check that the safety tab has not been removed.
• Make sure the tape is not at its end.
• Check that a tape is not already in the tape
compartment.
• Make sure you are pointing the remote commander at
the remote sensor on the unit.
• Replace all the batteries in the remote commander
with new ones if they are weak.
• Clean the cabinet, panel, and controls with a dry soft
cloth, or a soft cloth slightly moistened with a mild
detergent solution. Do not use any type of solvent,
such as alcohol or benzine.
• The demonstration mode has been turned on. Cancel
the demonstration mode by pressing STD PICT.
Sony Corporation
Demonstration mode
The demonstration mode will
activate when you press STD PICT
and the V RESOLUTION CONTROL
button on the unit at the same time.
When demonstration mode starts
during playback, RESOLUTION
CONTROL III menu appears and the
level of picture adjustment changes
automatically.
When demonstration mode starts during
power off and Synchronised Recording
off, the indicator lights on the unit flash.
To cancel the demonstration mode
Press STD PICT.
initial
contamination
terminal
Содержание
- Additional connections 1
- Checking your model name 1
- Connecting the areial 1
- Connecting the unit 1
- Ga35mkii 1
- Inserting the batteries 1
- Setting up the remote commander 1
- Slv ga35mkii 1
- Slv ga55mkii ga65mkii ga45av 1
- Slv ga59 1
- Step 1 1
- Step 1 unpacking 1
- Step 2 1
- Step 2 setting up the remote commander 1
- Step 3 1
- Step 3 connecting the unit 1
- Step 4 1
- Step 4 tuning your tv to the unit 1
- Tuning your tv to the unit 1
- Unpacking 1
- Using the remote commander 1
- Video cassette player 1
- About adaptive picture control apc 2
- About adaptive picture control apc slv ga55mkii ga65mkii ga45av and ga59 only 2
- About optimum picture control opc 2
- About optimum picture control opc slv ga35mkii only 2
- Adaptive picture control apc automatically improves recording and playback quality by adjusting the unit to the condition of the video heads and tape 2
- Additional tasks 2
- Adjusting the picture 2
- Adjusting the resolution and colour 2
- Adjusting the tracking 2
- Although the unit automatically adjusts the picture when playing a tape distortions or noise may occur if the tape was recorded in poor condition if so manually adjust the resolution colour and tracking 2
- Apc playback the apc function automatically works on all types of tapes including rental tapes and tapes that were not recorded with apc 2
- Apc recording whenever you insert a tape and start recording the unit adjusts to the tape using the apc function this adjustment is retained until the tape is ejected 2
- Connections necessary to use this function connect the unit and tv with the audio video cable be sure to connect the audio video cable to the video in 1 jacks on the tv if the tv has two inputs or more the tv must be placed where it will respond to the remote commander while you are pointing it at the unit 2
- Insert a tape 2
- Operation make sure that the tv s power is in standby mode 2
- Optimum picture control opc automatically improves playback quality by adjusting the unit to the condition of the video heads and tape 2
- Playing searching at various speeds 2
- Press h play if playback did not start in step 2 2
- Press m m resolution control v v button on the unit to get the best picture colour wait for several seconds until the adjustment menu disappears 2
- Press resolution control b b button on the unit to get a clearer picture 2
- Press trinitron tv synchro play and hold the remote commander in place for about two seconds 2
- Press v v tracking normal slow still adjust to obtain the best possible picture the distortion should disappear as you press one of the two buttons if you cannot get a clear picture with manual adjustment press tracking auto manu to return to automatic adjustment 2
- Slv ga35mkii e 3 063 086 11 1 2
- Slv ga35mkii the unit turns on and starts playing automatically 2
- Slv ga55mkii ga65mkii ga45av and ga59 the unit turns on and starts playing automatically if you insert a tape with its safety tab removed 2
- The opc function automatically works on all types of tapes including rental tapes and the tapes that were not recorded with opc 2
- The unit and tv turn on and the tv is set to the video channel if there is a tape in the unit playback starts automatically 2
- To play an ntsc recorded tape set ntsc pb on the unit according to the colour system of your tv 2
- To resume the automatic adjustment press standard picture on the remote commander std pict on the unit the adjustment menu appears for a few seconds then disappears 2
- To set the colour system if streaks appear during playback set color system on the unit to conform to the system that the tape was recorded in normally set the switch to auto 2
- To turn the display off press display again 2
- To view the tape status on the screen press display the following information appears on the tv screen 2
- Turn on your tv and set it to the video channel 2
- Turning on the unit and tv to start playback trinitron tv synchro play 2
- When the tape reaches the end it will rewind automatically 2
- While playing a tape press m m resolution control v v b b button on the unit so that the adjustment menu appears on the tv screen 2
- You can only use this function if your tv is made by sony trinitron tv 2
- Connections necessary to record on this unit 3
- Connections necessary to use this function 3
- Editing when recording on this unit 3
- Editing with another unit 3
- How to make a synchronised recording 3
- Slv ga55mkii ga65mkii ga45av and ga59 only 3
- Synchronised recording 3
- Auto head cleaner the unit incorporates an auto head cleaner which cleans the video heads when a tape is loaded or unloaded when the heads are not sufficiently clean even after a tape has been loaded unloaded several times use a video head cleaning cassette 4
- Be sure to use the sony t 25cld t 25clw or e 25cldr video head cleaning cassette if these cleaning cassettes are not available in your area have the heads cleaned at your nearest sony service facility a standard service charge will be required 4
- Demonstration mode 4
- General 4
- Head condition sensor 4
- Inputs and outputs 4
- Precautions 4
- Sapphire tape cleaner 4
- Specifications 4
- Supplied accessories 4
- Symptoms caused by contaminated video heads 4
- System 4
- The demonstration mode will activate when you press std pict and the v resolution control button on the unit at the same time 4
- The head condition sensor checks the conditions of video heads if the heads are dirty a message will instruct you to insert a video head cleaning cassette 4
- The unit incorporates a sapphire tape cleaner which cleans a video tape when it is loaded this cleaner can prevent the video heads from contamination by removing dust or mold from a tape with its sapphire edge 4
- To cancel the demonstration mode press std pict 4
- Troubleshooting 4
- Warning 4
- When demonstration mode starts during playback resolution control iii menu appears and the level of picture adjustment changes automatically 4
- When demonstration mode starts during power off and synchronised recording off the indicator lights on the unit flash 4
Похожие устройства
- AEG AMS7000U Инструкция по эксплуатации
- Maxwell MW-2216 BK Инструкция по эксплуатации
- Sony SLV-GA55ME Инструкция по эксплуатации
- Hotpoint-Ariston AQ7D 297 U (RU) Инструкция по эксплуатации
- Sony SLV-760HF Инструкция по эксплуатации
- Zanussi ZWO286W Инструкция по эксплуатации
- Sony ICF-C290 Инструкция по эксплуатации
- Bissell 1132N Инструкция по эксплуатации
- Sony ICF-C273 Инструкция по эксплуатации
- Mystery MSF-2408 Инструкция по эксплуатации
- Maxwell MW-2206 BK Инструкция по эксплуатации
- Sony ICF-C25 Инструкция по эксплуатации
- Lenovo G580 /59401558/ Инструкция по эксплуатации
- Maxwell MW-2205 W Инструкция по эксплуатации
- Sony ICF-C233 Инструкция по эксплуатации
- Asus N750JV 90NB0201-M00090 T4009H Инструкция по эксплуатации
- Sony ICF-C217 Инструкция по эксплуатации
- Maxwell MW-2204 BK Инструкция по эксплуатации
- Maxwell MW-2203 BK Инструкция по эксплуатации
- Acer Aspire V5-561G-74508G1TMaik Инструкция по эксплуатации
