Luxstahl MARCO Qwikbrew-6 [3/8] Installation

1900057 REV.3 3

INSTALLATION

PLUMBING

Water pressure: 5 - 50 psi (min.-max.)35 - 345 kPa (min.-max.)

1. Fit a stop valve on a cold water line and attach a ¾” BSP male fitting

2. Connect the straight tail-piece of the flexible hose to the stop valve fitting. Make sure

that pre-attached sealing washer is secure.

3. Connect the right angled tail-piece of the hose to the inlet valve of the brewer (in the

base of the machine); again making sure that the pre-attached sealing washer is secure.

4. Turn on water supply and check that the fittings have sealed.

5. A hose is not a permanent connection so it is advisable to close the stop valve when not

in use for long periods (e.g. weekends/holidays)

For model 1000384 Push Button Rear Delivery, there is an optional drain hose to allow urn to be

emptied into a drain or container by turning the key on the side panel. However the bunged hose

must be replaced with a suitable hose to facilitate this.

For model 1000385, the Coffee and Hot Water output is controlled via Front Push Buttons. These

operate in a “Push and Hold” mode. To drain the coffee urn a key switch is located at the front on

the unit. When operated this key switch will open the Coffee output valve and allow the coffee urn

to drain. A suitable container should be used.

ELECTRICAL

When installing the product, always observe the local regulations and standards.

Products without an electrical plug are to be connected by an authorised professional

installer.

N.B. THESE APPLIANCES MUST BE EARTHED!
